Fiber Optical Cable

Fiber optical cable
Fiber cable optical fiber cable, optical cable, indoor/outdoor fiber optical cable, breakout tight buffer armored

Product Name:
Indoor/Outdoor fiber optical cable, breakout tight buffer armored

Specification:
1) Fiber count:2core 4core 6core 8core 12core
2)OD:8.0 9.3 10.5 13.2MM
3)TB diameter:2.0
4)Cable weight:65.0 68.0 85.0 110.0 170.0 kg/km
5)Fiber(Core) type:62B(=MM 62.5/125um grade B)
62A(=MM 62.5/125um grade A)
50A(=MM 50/125um grade A)
50B(=MM 50/125um grade B)
Om3(=MM 50/125um grade B)
009(=SM 9/125um)
6) Sheath material:PE, LSZH, Plenum
7) Color:Black, blue, green, grey, orange, red, white, yellow

Description:
- Tight buffered fiber without jelly compound
-Sub-unit with aramid yarn strength members
-Reduce weight for longer span lengths
-Non-metallic central strength member
-Laminated Alunmiun tape armor
-Waterproof and appplicable environment curiness
-The termination can be made standard connector
-Ususlly, SM:Yellow;MM:Organge outer sheath

Application:
Suitable for aerial pipeline, bracket laying
Suitable for indoor and outdoor cable

Quality Assurance System:
Optical testing follows ITU, IEC and EIA/TIA-FOTP
