FC/PC SM 3.0mm Fiber Optic Connector

FC/PC SM Fiber Optic Connector

Specifications

Fiberoptic patch cord
Manufacturer
100% tested before delivery
Custom Cable, Connector.
Good Quality at Fair Price

Description
Fiber Optic Connectors are ultra reliable components featuring low insertion loss and return loss. They come with your choice of simplex or duplex cable configuration and are made to conform to IEC, Telcordia GR-326-CORE Standard.

The performance of the Fiber optic connector has been carefully designed to meet the IEC standards, GR-326-CORE, in the test of optical characteristics, vibration test, thermal cycling, impact resistance, salt spray erosion, thermal aging, humidity resistance and others.

Usage environment
Operating temperature: -40º C~+75º C

Features
1. Low insertion loss and back reflection loss
2. Ferrule end surface pre-domed
3. Boots in a variety colors
4. Telcordia style boots
5. Free-floating ceramic ferrule

Photoelectricity specifications
1. Insertion loss: ≤ 0.2dB
2. Return loss: ≥ 65dB
3. Durability: ≤ 0.1dB typical change, 500mating

Applications
1. Active device termination
2. Multimedia
3. Premise installations
4. Telecommunication networks

Insertion Loss; Single mode<=0.2dB & Multimode<=0.3dB
Return Loss; PC>=50dB, UPC>=55dB & APC>=65dB
Durablity <0.2dB typical change, 1000 mating
Operating Temperature; -40 to 80
Ferrule Hole Sizes;
Singlemode
125.0+1/-0um, concentricity<=1.0um
125.5+1/-0um, concentricity<=1.0um
126.0+1/-0um, concentricity<=1.0um
Multimode;
125um concentricity <=3um
127um concentricity <=3um
128um concentricity <=3um

Availability

The connector can be supplied as a pre-assenbled one piece or one piece or as connector kit.
Clips are avaliable for SC and LC duplex connector.
Boots in a varity of colors.
PC and APC, UPC are availiable.
