GS-Ls/C-1 LED Solar Powered Marine Lanterns

Scope of Application
GS-LS/C-1 LED Solar Powered Marine Lanterns can be provided with power supply without power transmission cables by solar power, so it is suitable for those locations especially which are hard to lay the cable or lack of power supply. GS-LS/C-1 LED Solar Powered Marine Lanterns is commonly used on both fixed and floating structures for Aids to Navigation.

Main Parameter

1. Mode: GS-LS/C-1
2. FAA Standard: IALA
3. Visible distance:up to 4 Nautical Miles
4.Light intensity:32 cd
5. Flash rate: Flash mode
6. Light source: LED
7.Light character(Flash Patterns):Flash mode or Steady-burning
8.Horizontal output:360 degree
9.Vertical Divergence:At least 70 at 50% maximum intensity
10. Service life of LED: 100, 000hours
11. Operating voltage: DC6.4V, recyclable batteries with the lightest environmental and long life.
12. Power Consumption: 4W
13. Overall Size(mm): φ220 by 233
14. Installation Size:φ190 by M10
15. Weight:2Kg
16. Emitting Color: Red,Green,Yellow(Amber) and White.
17. Ambient Temperature: -55degree centigrade to +60degree centigrade
18. Wind load: 80m/s
19. Control Way: Photocell. Light can work at night or low visility during the day automatically by photocell.

Option Function

1. Remote Control function.Turn on and off lights open place in 3km without obstacle(effective distance) by Remote controller.
2. GPS Syn Function.All Marine Lanterns can flash at the same time by GPS.

Dimension Drawing

Product Profile

1. Model: GS-LS/C-1
2. Applications: Applied to both fixed and floating structures.
3. Standard: IALA
4. Improve Records:None
5. Fault Records: None
6. Quantity/Delivery Day: 20 pcs / 10 Days
