GS-Ls/C-6 LED Solar Powered Marine Lanterns

GS-LS/C-6 LED Solar Powered Marine Lanterns

Advantages
1. 3 to 6 Nautical Miles (Tc=0.74)
2. PC material with good impact protection strength, thermal stability, high transmittance.
3. International advanced solar panel reaching at least 10 years service life.
4. Comprehensive protection in voltage short, overvoltage, floating Charge and temperature.
5. International-advanced cold and special LED with low power consumption, high brightness and service life of light source reaching 100000hours.
6. Strong corrosion resistance, Rain and Rain, Shock and Vibrations protection and UV protection.
7. Clean, renewable, green and reliable energy source.
8. Dusk-to-dawn operation: New technology application. Light can work at night automatically by solar panel which function is equal to photocell sensor.
9. At least 5 days autonomy without sunshine.
10. Recyclable batteries with the lightest environmental.
11. IP67 protection standard, Full sealing structure.

Scope of Application
GS-LS/C-6 LED Solar Powered Marine Lanterns can be provided with power supply without power transmission cables by solar power, so it is suitable for those locations especially which are hard to lay the cable or lack of power supply. GS-LS/C-6 LED Solar Powered Marine Lanterns is commonly used on both fixed and floating structures for Aids to Navigation.

Main Parameter
1. Mode: GS-LS/C-6
2. FAA Standard: IALA
3. Visible distance: 3 to 6 Nautical Miles
4. Light intensity: 35cd(3NM), 70cd(4NM), 150CD(6NM)
5. Body Material: Profession Marine Aluminium Alloy
6. Light character: option 256 characters.
7. Flash rate: Flash mode or Constant mode
8. Light source: LED
9. Service life of LED: 100, 000hours
10. Operating voltage: DC12V, recyclable batteries with the lightest environmental and long life.
11. Overall Size(mm): 260 by 260by 440
12. Installation Size(mm): 220 by 220by M10
13. Weight: 7Kg
14. Emitting Color: White, Amber(Yellow), Red, Green
15. Ambient Temperature: -55 degree centigrade to +70 degree centigrade
16. Wind load: 80m/s
17. Control Way: Photocell. Solar panel which function is equal to photocell sensor can let light work at night and close during the day automatically.

Option Function
1. Remote function function. Turn on and off lights open place in 3km without obstacle(effective distance) by Remote controller.
2. GPS Syn Function. All Marine Lanterns can flash at the same time by GPS.
3. Ajustable 256 characters.

Dimension Drawing

Flashing rate and intensity adjustion
F fix
FL Flashing in fixed time, for example: FL (2) 5.5 S flashes twice every 5.5 seconds
Q Flashing
VQ Quick flashing
OC Bright and dark light, Lighting time longer than extinguish time.
ISO Equal light, Lighting time is equal to the extinguish time
LFL Long time, long flash
MO Morse signals, including letters
For example: VQ (6) + LFL 15 S6 times within 15 seconds then long flashes once.
As for 256 light character table, please contact Business Manager to get it.

Product pictures

Product Profile
1. Model: GS-LS/C-6
2. Applications: Applied to both fixed and floating structures.
3. Standard: IALA
4. Improve Records: None
5. Fault Records: None
6. Quantity/Delivery Day: 20 pcs / 10 Days
