GS-AWS Aircraft Warning Sphere

Get Latest Price

Payment Type:: T/T, Western Union

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	Shenzhen, China
Payment Type:	T/T, Western Union

Product Description

GS-AWS Aircraft Warning Sphere

Main Parameter
1. Conforms to ICAO Item 14
2. Diameter of Aircraft Warning Sphere: Φ 600mm
3. Color: Orange, Red or White
4. Material: Fiber glass reinforced polyester resin
5. Character of fiber glass:
-Tensile strength more than or equal to 128Mpa
-Bending strength more than or equal to 230Mpa
-Temperature resistant: 40 degree centigrade to 90 degree centigrade
6. Fastener: Stainless steel material, M10 by 35, M10 by 40
7. Weight of Sphere: 6.3Kg

Scope of Application
Designed to use for high-rise transmission lines, espcacially for EHV (500, 000KV)
Transmission cables, river-crossing transmission lines to provide the warning marks.

Installing Step:
1. At the mount point on the alerting ball, wrap cable protecting bars round cables for 1000-1200mm long, with two ends of protecting bars extending 200-300mm beyond the Surface of the ball.
2. Fix the plastic wires which are mounted on lower hemisphere of the ball onto the cables and twist them.
3. Combine the lower hemisphere with the upper hemisphere according to module codes.
Turn the hemisphere during the assembly and make sure two hemispheres are joined into Position.
4. Insert stainless steel bolt(M12*35) and then put flat washers and spring washers Around each bolt. Tighten each nut at last.

Installation Drawing

Product Profile
1. Model: GS-AWS
2. Applications: Applied to High-rise transimission lines, Transmission cables, river-crossing transmission lines.
3. Standard: ICAO Annex 14
4. Certificate: CAAC Certificate(ICAO Certificate)
5. Improve Records: None
6. Fault Records: None
7. Quantity/Delivery Day: 300 pcs / 15 Days
