Attenuator Female-Female ST/PC Sm/Adapter

Product Name: Attenuator Fixed ST/PC SM /Attenuator/Adapter

P/N: LA100313009
Description:
APPLICATION
Low Insertion Loss Deviation
Fiber Optic Communication Systems
Variable of attenuation ways and a bound of connector types
Fixed Type: Attenuator/Adapter
Local Area Networks (LAN)

SPECIFICATIONS
Attenuation Range: 0-30dB
Available Wavelengths: 1310nm or 1550nm
Fixed attenuation value: 1\2\3\5\10\15\20dB or optional
Return Loss: ≥ 50 dB (SPC) or ≥ 60 dB (APC)
Polarization Dependent Loss: ≤ 0.2dB
Temperature Range: -40 -80
Humidity Range: +/- 0.2 dB Change in 10% to 90% relative
Vibration: ≤ 0.1 dB change between 10Hz to 55Hz
Drop: +/- 0.2dB after 8 drops (3 axes) from 1.8 meters onto a hard surface

ORDERING OPTIONS
Connector type: FC-FC, SC-SC, FC-SC, SC-ST, LC-LC
Typical attenuation value: 1\2\3\5\10\15\20dBor optional
Attenuation form: Isolation type
