Cat5e LAN Cable (L10811) /Patch Cable

Cat5e Cable/ Cat5e LAN cable/ cat5e network cable/Patch Cable
PRODUCT DESCRIPTION
1. This kind of cable use bare copper to be the center conduction, with the Specification is 24AWG; PE is adopted to be the dielectric, Each pair of the Coppers is covered by polyester film and AL foil even outer. The earth wire is Installed between these two covers. The jacket is made of fireproof material, and It's so significative to the Cat. 5e communication.
2. This Cat. 5e FTP cable is well conformed to the ISO/IEC, TIA/EIA and EN standards And whose electrical characteristics are exceed the lastest ISO/IEC Cat. 5e Standards.
3. LSZH: Means "Low smoke zero halogen", which is the symbol of environmental Protection.

ELECTRICAL CHARACTERISTICS
1. Impedance: 100± 15
2. Static electric capacity: Max: 17.1nf/kf
3. Resisitance: Max: 28.6/kf
4. Unbalance resisitance: Max 5%
5. Unbalance capacity: Max 330pF/100m
6. Roted communicate rate: 65%

PHYSICAL CHARACTERISTICS
1. Copper diameter: 24AWG
2. Outer diameter: 6.1mm
3. Shielding material: AL foil
4. Earth wire: No. 24 bare cop
