Cat5e 90 Degree Unshield Keystone Jack (L20101)

Cat5e 90 Degree Unshield Keystone Jack (L20101)

Get Latest Price

Payment Type:: L/C, T/T, Western Union

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	China
Payment Type:	L/C, T/T, Western Union

Product Description

Cat5e 90 Degree Unshield Keystone Jack (L20101)
Features and Benefits
Use 110 tool to install
Front contact with excellent flexibility & reliability
Meets FCC part 68 standards
Physical specification
Material
Plastic: High impact flame retardant plastic, UL94V-0
Contact: Phosphor bronze C5210EH
Contact plating: Gold plating 50u" over nickel plating 50~100u"
Mechanical
Plug insertion life: 750 cycle min
Plug retention force: 30Lbs min
IDC contactor: Accept 22-26 AWG solid wires
Temperature: -40 to 70
Electrical Performance
Current rating: 1.5 AMP
Insulation resistance: 500Mega ohms min
Contact resistance: 20milli-ohms max
Dielectric strength: 750V AC RMS 60Hz 1MIN
