PCB and Assembly, Purchase Components, Turnkey Solution

Get Latest Price

Payment Type:: L/C, Paypal, Western Union

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	Shenzhen, Guangdong, China
Payment Type:	L/C, Paypal, Western Union

Product Description

OVER 10 YEARS DIP/SMT Electronic pcb assembly Services , electronic pcba prototype assembly, OEM Electronic Manufacture Service.

One-stop electronic manufacture service, We can offer 1 to 30 Layer PCB fabrication, PCB design, PCB layout, PCB manufacturing, PCB assemblies, wire harness assembly,IC programing,components sourcing, PCBA Function Test.

Manufacture Capacity

PCB Item

Layer Counts: 1 - 30L

Base Material: FR4,High-Tg FR4,CEM1,CEM3,aluminum,High Frequency(Rogers,Taconic,Aron,PTFE,F4B)

Material Thickness(mm): 0.40, 0.60, 0.80, 1.00, 1.20, 1.50, 1.60, 2.0, 2.4, 3.2

Max Board Size: 1200mm x 500mm(48" x 20")

Board Outline Tolerance: ±0.15mm(±6mil)

Board Thickness: 0.4mm(16mil) - 3.2mm(128mil)

Thickness Tolerance: ±10%

Minimum Line/Space: 0.1mm(4mil)

Min Annular Ring: 0.1mm(4mil)

SMD Pitch: 0.3mm(12mil)

Holes

Min Hole Size: mechanical hole-0.2mm(8mil), laser hole-0.1mm(4mil)

Hole Size Tolerance: PTH: ±0.075mm(±3mil);NPTH: ±0.05mm(±2mil)

Hole Position Tolerance: ±0.075mm(±3mil)

Plating

HASL/LF: HAL2.5um(100u")

Immersion Gold/Nickel: 3-7um(120-210u") Au:0.025-0.125um(1-5u'')

Surface Finish: HAL,lead-free HAL,ENIG,Plated Gold,Immersion Gold,OSP,etc.

Copper

Copper Weight: 0.5 - 6oz

Color

Soldermask: Green, Blue, Black, White, Yellow, Red, Matt Green, Matt Black, Matt Blue

Silkscreen: White, Black, Blue,Yellow

Acceptable File Format
Gerber file,Powerpcb,CAD,AUTOCAD,ORCAD,P-CAD,CAM-350,CAM2000

Certificate
ROHS,ISO9001,TS16949,UL,IPC,SGS

PCBA Item

Stencil Size/Range: 736 x 736mm(29.44 x 29.44")

Minimum IC Pitch: 0.30mm(12mil)

Maximum PCB Size: 1200 x 500mm(48 x 20")

Minimum PCB Thickness: 0.35mm(14mil)

Minimum Chip Size: 0201 (0.2 x 0.1mm)/0603 (0.6 x 0.3mm)

Maximum BGA Size: 74 x 74mm(2.96 x 2.96")

BGA Ball Pitch: 1.00mm(40mil)minimum, 3.00mm(120mil)maximum

BGA Ball Diameter: 0.40mm (16mil)minimum, 1.00mm(40mil)maximum

QFP Lead Pitch: 0.38mm(15.2mil)minimum, 2.54mm(100mil)maximum

Frequency of Stencil Cleaning: 1 time/5 to 10 pieces

If you need to get a formal quoation, please provide the spec as below:

1. PCB files in gerber file
2. Parts list(BOM list)

Welcome to contact Fulltronics team. We are here ready to assist you with our professional skills and cheerful services!
