45W Laptop Adapter 14.5V3.1A Power Charger for Magsafe 2

Model No.
YAPS06
AC Input
Nominal Input Voltage
AC 100V~240V
Input Voltage Range
AC 95V~265V
Input Frequency
50/60Hz
DC Output
Output Voltage
14.85V
Output Current
3.05A
Output Power
45W
DC Connector Size
FLAT
Line Regulation
2%
Load Regulation
5%
Ripple Noise
180 MVP-p
Efficiency
>85%
Output Cable Standard
0.5mm2 Pure Copper
Output Cable Length
1.5m normally or customized requirement
Environment
Operating Temperature
0° C ~40° C
Operating Humidity
5%~95%RH
Storage Temperature
-20° C ~85° C
Storage Humidity
5%~95%RH
Protection
Over Load Protection
Short Circuit Protection
Over Current Protection
Over Temperature Protection
Certificates
CE, RoHS, REACH, FCC, ERP, CB, GS, TUV, UL, cUL, CCC, PSE
Dimensions
Adapter Size
7.5*7.5*3.2CM
Adapter Weight
290G
Inner Box Size
19*13*4.7CM
Inner Box Weight
40G
PCS/CTN
50PCS
Outer Carton Size
48.5*32*40CM
Outer Carton Weight
860G
GW/CTN
17360G
Package
Inner Box
Normally neutral brown box or customized requirement
Outer Carton
Normally neutral standard carton or customized requirement
Warranty
Guarantee
30 days
Warranty
2 years
Terms and Conditions
MOQ
100PCS for mixed order
Payment Terms
T/T, L/C, PayPal, western union
Delivery Time
3-5 days
Manufacturing Process
1. Set-Up2. Hand Insertion3. Wave Soldering4. Touch-Up5. V/I6. ICT7. INT8. Apply Glue9. Q/A10. Entering Stock11. Assembly12. Power On Test13. Hi-Pot Test14. Burn-In15. Hi-Pot Test16. All Fun Test17. Packing18. OQC19. Shipping
Test Procedures
1. No-load output voltage test2. Input power load test3. No-load output ripple test4. Full load open test5. Full load output voltage test6. Full load output ripple test7. Full load input power test8. Half load output voltage test9. Half load output ripple test10. Over load test11. Over current protection test 12. Short circuit protection test (above test is under both 110V and 230V. )13. High voltage test14. Burn-in test15. Turn on delay time test16. Rise time test17. Hold time test18. Overshoot test
