Gl300 Guider

Receiver-Features:
>>> 6 keys and LCD user interface easy and quick to locate
>>> Advanced FM modulation offers strong performance against noise
>>> 0.1% resolution pitch based on advanced MEM technology
>>> With over 5 data telemetry channels, up to 600 meters range
>>> Ergonomically designed plastic housing reduce the fatigue
>>> Flash memory technology allows in field program update
>>> Easy to understand pictorial instruction decals

Data Sheet:
>>> System freq: 30Khz
>>> Batteries: 6 C-cell off shelf batteries/rechargeable battery
>>> Batteries life: 18/10 hours continuous operation.
>>> Display: Industrial rated LCD graphic display
>>> Telemetry: 5 channels of license free radio. Range up to 600m
>>> Dimensions: 30cmx13cmx67cm
>>> Water proof: IP65


Display-Features:
>>> With 6 keys and LCD user interface identical to that of locator
>>> 5 data telemetry channels, up to 600 meters
>>> Rouged plastic house with easy dash magnetic mounting
>>> Flash memory technology allows in field program update
>>> Can be powered with 6 C-cell batteries or by a 12-32 VDC
>>> With a standard J1939 CAN bus

Data Sheet:
>>> Power: 6 C-cell off shelf batteries or 12-32 VDC of a HDD
>>> Batteries life: 18 hours continuous operation with 6 C-cell batteries
>>> Display: Industrial rated LCD graphic display
>>> Telemetry: 5 channels of license free radio with range up to 600m
>>> Dimensions: 14cmx13cmx13cm
>>> Water proof: IP65


Transmitter-Features:
>>> Solid state IC design with high accuracy pitch, roll and temperature sensors
>>> Advanced modulation offers strong performance against the noise
>>> 0.1% resolution pitch based on advanced MEM technology
>>> Flash memory technology allows program field updateable
>>> Standard dimension compatible with most current drill housing
>>> Temperature warning

Data Sheet:
>>> Transmitting freq: 30Khz
>>> Batteries: 2 C-cell off shelf batteries.
>>> Batteries life: 12 hours continuous operation
>>> Range: Up to 18 meters depth
>>> Roll: 12 o'clock segment
>>> Pitch: 0.1% resolution
>>> Temperature: Under 85 degree centigrade
>>> Weight: 0.68KG
>>> Dimensions: Standard
>>> Water proof: IP67
