Thermal Imaging Detector (KL20A-15)
- Payment Type:
- T/T
Quantity:
Your message must be between 20 to 2000 characters
Contact NowBasic Info
Basic Info
Place of Origin: | Shenzhen, China |
---|---|
Payment Type: | T/T |
Product Description
Product Description
Feature: With flexible thermal image camera head, UFPA, 160x120 pixel. Suitable for dark, fog, smokingenvironment surveillance. Against hijack and kidnap, search for victims after disaster. H. 264 video compression, 4in LCD screen, real time video.
Detector characteristics
— Detector type Uncooled FPA microbolometer α -Si
— Array size 160x120, 25μ M
— NETD ≤ 80mk@25
— Spectral range 8~14μ M
— Image manage Lens 15mm Germanium lens
— Field of view 15.3(H) x 11.5(V)
— Spatial resolutions(IFOV) 1.67mard.
— Frame rate 50Hz(PAL) / 60Hz(NTSC)
— Calibration Auto/manual
— Electronic zoom 2x
Image presentation
— Video output PAL or NTSC
— Video compression H. 264
— Video file format AVI
— Display 4.0 inches turning-over LCD screen
— Image storage SD card
— Interface USB 2.0
— Battery Type High capacity Lithium Battery
— Voltage 3.7V / 2200mAh
— Recording time 3~4 hours
Environment
— Operating temperature -20 ~ +55
— Storage temperature -35 ~ +65
— Encapsulation IP66
Physical characteristics
— Material Al-alloy
— Weight 2.45kg
— Length max up to 5 meters
— Stantard packing Thermal Camera, User manual, Li-battery, Charger, 2PCS extension pipes, AV and USB cables, SD card, Aluminium box
Detector characteristics
— Detector type Uncooled FPA microbolometer α -Si
— Array size 160x120, 25μ M
— NETD ≤ 80mk@25
— Spectral range 8~14μ M
— Image manage Lens 15mm Germanium lens
— Field of view 15.3(H) x 11.5(V)
— Spatial resolutions(IFOV) 1.67mard.
— Frame rate 50Hz(PAL) / 60Hz(NTSC)
— Calibration Auto/manual
— Electronic zoom 2x
Image presentation
— Video output PAL or NTSC
— Video compression H. 264
— Video file format AVI
— Display 4.0 inches turning-over LCD screen
— Image storage SD card
— Interface USB 2.0
— Battery Type High capacity Lithium Battery
— Voltage 3.7V / 2200mAh
— Recording time 3~4 hours
Environment
— Operating temperature -20 ~ +55
— Storage temperature -35 ~ +65
— Encapsulation IP66
Physical characteristics
— Material Al-alloy
— Weight 2.45kg
— Length max up to 5 meters
— Stantard packing Thermal Camera, User manual, Li-battery, Charger, 2PCS extension pipes, AV and USB cables, SD card, Aluminium box
