25.9V 7s 10A Battery Charger Circuit Board PCM-L07s10-269

Specifications

1, 25.9V 7S 10A battery charger circuit board PCM-L07S10-269 2, Current: 10a 3, Detection delay time 1~50ms 4, Release condition C.


No. Test itemCriterion
1Voltage: Charging voltage: CC/CV:
Li-ion/Li-polymer(4.2V/cell);
LiFePO4(3.6V/cell)
Balance voltage for single cellLi-ion: 4.20 V± 0.025V, LiFePO4: 3.60V± 0.025V
2CurrentBalance current for single cell0~85mA
Balance current for single cell≤ 20μ A
Maximal continuous charging and discharging current10A
3Over-charge ProtectionOver charge detection voltage3.8~4.4V(can adjust)
Over charge detection delay time0.5~2.5S
Over charge release voltage3.8~4.4V(can adjust)
4Over-discharge ProtectionOver discharge detection voltage1.9~3.1V(can adjust)
Over discharge detection delay time50~300mS
Over discharge release voltage1.9~3.1V(can adjust)
5Over-Current ProtectionOver current detection voltage0.6V
Over current detection current30~100A
Detection delay time1~50ms
Release conditionCut load
6Short ProtectionDetection conditionExterior short circuit
Detection delay time200-500us
Release conditionCut load
7ResistanceProtection circuitry(B- to P-)≤ 20mΩ
8TemperatureOperating temperature range-40~+85° C
Storage temperature range-40~+125° C
9Size
Φ 80mm




We have over six hundreds of PCM/BMS series products for your choice, most of them widely used for Li-ion battery pack, Li-Polymer battery pack, LiFePO4 battery pack and so on.
Main components for our PCB/BMS normally adopt imported raw material for relaible quality control and zero RMA.


PCM for 1-5S Li-ion/Li-Polymer/LiFePO4 battery pack
PCM for 6-35S Li-ion/Li-Polymer/LiFePO4 battery pack(With balancing function can be added)
PCM for high rate/high power Battery Pack
PCM for E-bike/E-scooter/E-motorcle/E-tool etc battery pack
Battery fuel guage/Battery charging management system
All kinds of customized PCM/BMS OEM/ODM welcome
