150W Single Output Waterproof LED Driver

1. High efficiency 91%
2. Low cost, high reliability
3. Full range 90~130VAC/170~250VAC
4. Protections:
. Short-circuit
. Over-load
. Over-voltage
. Over-temperature
5. Working temperature: -40 degree~ + 70 degree
6. IP67 design for indoor and outdoor applications
7.2~3 times burn-in tests (+50 degree/-40 degree at full load with over 14 hours)
8. Protection
1)Current protection-----± 1% (current limiting type) Constant current limit, recovers after faulty problem
Is removed
2)Over-Voltage-------110% ~ 130% (Shut down O/P voltage, repower on to recover)
3)Over-load-----------130% ~ 150% (Shut down O/P voltage, repower on to recover)
4)Short Circuit------Hiccup mode, recovers automatically after faulty problem is removed
5)Lightning Protection----Gas discharge tube automatically open to discharge, repower on to recover
6)Over-temperature------85degree± 10degree (Shut down O/P voltage, re-power on to recover)
9. Safety & EMC
1)Safety Standards------EN-61347-1, EN61347-2-13, IP67, ROHS Tests, Design refer to UL8750
2)Withstand Voltage-----I/P-O/P: 3KVAC, IP-FG: 1.5KVAC, OP-FG: 500VAC
3)Isolation Resistance----I/P-O/P IP-FG OP-FG: 100M Ohms/500VDC / 25degree / 70% RH
4)EMC Emission-------Compliance to EN55015: 2007, EN61547: 1995+A1: 2000; EN61000-3-2: 2006;
EN61000-3-3: 2008
5)EMC Immunity-------Compliance to EN55015 EN61547 EN61000-4-2, 3, 4, 5, 6, 8, 11
