4 Channel Fiber Telephone Multiplexer

Description:

This device provides 4Channel telephone 1-4Channel E1 interface, 4Channel 10M/100M Ethernet interface
(Line Speed 100M) and 4 expansion interface. 4Channel Ethernet interface is switch interface, can support
VLAN. 4 expansion interface can be used as the transmission channeof RS232/RS485/RS422 asynchronous data, voice signal, 2/4 line E&M audio signal, switch signal, Ethernet signal (Bandwidth 2M). It is very flexible.

Features
# Based on self -copyright IC
#E1 interface comply with G. 703, adopts digital clock recovery and smooth phase-lock technology
#Voice port supports FXO and FXS port, EM2/4 audio interface, FXO port docking with program-controlled switchboard, FXS port connected to the user's telephone;
#Voice FXO/FXS access, supports caller ID feature and reverse polarity billing functions
#Support various sites mutual number allocation function
#Provide 4 expansion interface, you can extend 1~4Channel asynchronous data, such as RS232/RS485/RS422/Manchester code; 1~4Channel voice, 1~8Channel switch, or two/four line audio #Ethernet interface supports10M/100M, half/full duplex auto- adaptable, support VLAN
#4Channel Ethernet interface is switch interface, support VLAN, can set to 4 channel logical isolation
# Ethernet interface can support AUTO-MDIX (crossed line and straightly connected line self-adaptable )
#The transmission distance is up to 2-120Km without interruption
#AC 220V, DC-48V, DC24V can be optional

Technical parameters:
Fiber
Multi-mode Fiber
50/125um, 62.5/125um,
Maximum transmission distance: 5KM@62.5/125um single mode fiber, attenuation (3dbm/km)
Wave Length: 820nm
Transmitting power: -12dBm (Min) ~-9dBm (Max)
Receiver sensitivity: -28dBm (Min)
Link budget: 16dBm
Single-mode Fiber
8/125um, 9/125um
Maximum transmission distance: 40Km
Transmission distance: 40KM@9/125um single mode fiber, attenuation (0.35dbm/km)
Wave Length: 1310nm
Transmitting power: -9dBm (Min) ~-8dBm (Max)
Receiver sensitivity: -27dBm (Min)
Link budget: 18dBm

E1 Interface
Interface Standard: Comply with protocol G. 703;
Interface Rate: N*64Kbps± 50ppm;
Interface Code: HDB3;
E1 Impedance: 75Ω (unbalance), 120Ω (balance);
Jitter tolerance: In accord with protocol G. 742 and G. 823
Allowed Attenuation: 0~6dBm

Ethernet interface (10/100M)
Interface rate: 10/100 Mbps, half/full duplex auto-negotiation
Interface Standard: Compatible with IEEE 802.3, IEEE 802.1Q (VLAN)
MAC Address Capability: 4096
Connector: RJ45, support Auto-MDIX

FXS Phone Interface
Ring voltage: 75V
Ring frequency: 25HZ
Two-line Impedance: 600 Ohm (pick up)
Return loss: 40 dB

FXO Switch Interface
Ring detect voltage: 35V
Ring detection frequency: 17HZ-60HZ
Two-line Impedance: 600 Ohm (pick up)
Return loss: 40 dB
EM 2/4 Line
AD: 0dB
DA: -3.5dB
Two/Four-line Impedance: 600 Ohm
Return loss: 20 dB

Power
Power supply: AC180V ~ 260V; DC 48V; DC +24V
Power consumption: ≤ 10W

Dimension
Product Size: Mini Type 216X138X31mm(WXDXH)
19 inch 1U 485X200X45mm(WXDXH)
Simple Packaing: Mini 274X193X84mm(WXDXH)
19inch 522X263X82mm(WXDXH)
Piece Wieght: Mini 1KG / 19inch 2.4KG

Working environment
Working temperature: -10° C ~ 50° C
Working Humidity: 5%~95 % (no condensation)
Storage temperature: -40° C ~ 80° C
Storage Humidity: 5%~95 % (no condensation)
