Sc/APC- Sc/APC Simplex Optical Fiber Patch Cord
- Payment Type:
- T/T, Paypal, Western Union
Quantity:
Your message must be between 20 to 2000 characters
Contact NowBasic Info
Basic Info
| Place of Origin: | Shenzhen Gungdong |
|---|---|
| Payment Type: | T/T, Paypal, Western Union |
Product Description
Product Description
Detailed Product Description
We offers single mode and multimode FC SC/APC patch cord, SC-LC, SC-ST, SC-FC, SC-MU, SC-MT-RJ, SC-E2000, etc types custom design SC fiber optic patch cord. Assemblies, 9/125(G. 657A, G. 657B, G. 655, G. 652D), 50/125, 62.5/125, SM, MM, simplex, Duplex. Any other specification is available on request.
Applications:
CATV, LAN, MAN, WAN, FTTH, FTTB;
Fiber-optical communications system;
Test & Measurement, Industry, Medical.
Features:
Good interoperability;
Low insertion loss;
Fiber diameter: Φ 0.9, Φ 2.0, Φ 3.0;
Ceramic ferrules, PC, UPC and APC polishing;
PVC or LSZH jacket cable.
We offers single mode and multimode FC SC/APC patch cord, SC-LC, SC-ST, SC-FC, SC-MU, SC-MT-RJ, SC-E2000, etc types custom design SC fiber optic patch cord. Assemblies, 9/125(G. 657A, G. 657B, G. 655, G. 652D), 50/125, 62.5/125, SM, MM, simplex, Duplex. Any other specification is available on request.
Applications:
CATV, LAN, MAN, WAN, FTTH, FTTB;
Fiber-optical communications system;
Test & Measurement, Industry, Medical.
Features:
Good interoperability;
Low insertion loss;
Fiber diameter: Φ 0.9, Φ 2.0, Φ 3.0;
Ceramic ferrules, PC, UPC and APC polishing;
PVC or LSZH jacket cable.
| TBC | _ | SC | / | PC | _ | SC | / | PC | / | SM | _ | SX | / | 2.0 | _ | 3M | |
| 0 | 1 | 2 | 3 | 2 | 4 | 5 | 6 | 7 | |||||||||
| 0 | Brand name | ||||||||||||||||
| 1 | Connector#1 LC,SC,FC,ST,E2000,DIN,D4,MU,MTRJ,etc. | ||||||||||||||||
| 2 | Lapping Way PC&APC (For MTRJ, F=Female, M=Male) | ||||||||||||||||
| 3 | Connector#2 LC,SC,FC,ST,E2000,DIN,D4,MU,MTRJ,Pigtail,etc. | ||||||||||||||||
| 4 | Cable Type SM(9/125μm) ,MM(50/125μm & 62.5/125μm) | ||||||||||||||||
| 5 | Fiber Number SX(Simplex) or DX(Duplex) | ||||||||||||||||
| 6 | Cable Diameter 2.0=Ø2.0mm, 3.0=Ø3.0mm, 0.9=Ø0.9mm, etc. | ||||||||||||||||
| 7 | Cable Length 3m(Length in meter) | ||||||||||||||||
| Descriptions | SM(PC) | SM(UPC) | SM(APC) | MM(PC) |
| Insertion loss | <0.3dB | ≤0.2dB | <0.3dB | <0.3dB |
| Return loss | ≥50dB | ≥50dB | ≥65dB | ≥35dB |
| Repeatability | ≤0.1 | ≤0.1 | ≤0.1 | ≤0.1 |
| Durability | <0.1dB typical change,1000 mating | |||
| Interchangeability | ≤0.2dB | |||
| Vibration | ≤0.2dB | |||
| Operating Temperature | - 20°C ~ + 70°C | |||
| Storage Temperature | - 40°C ~ + 80°C | |||
| Cable Diameter | 3.0mm, 2.0mm, 0.9mm | |||
