Practical Patent Tube Cct Lux Display Case Tester Power Meter

Practical patent tube cct lux display case tester power meter

Features of LED tube tester

1,Input voltage : AC 100V-250V. The input Voltage is the same as the testing Voltage. If test T8 fluorescent tube with the Magnetic ballast inside the tester,

the input voltage should be AC 200V-250V,50Hz. If test LED lamp or other lamps without ballast inside the  meter, the input voltage should be AC 100V-250V. 50-60Hz.

2, It could test not only the lighting products but also the other electrical products with Voltage range 100V-250V.

3, Maximum testing wattage: 300W.

4,Testing parameters: LUX,CCT,Voltage, Current , Power, Power factor, Annual power
consumption.(Calculated based on 10 hours/day).

5,It could test two pieces different electrical products at the same time.It also could test the dimmer bulb freely.

6,TEST1 with magnetic ballast inside could test T8 fluorescent tubes of
20W(60cm),30W(90cm),36W(120cm) and 58W(150cm).TEST2 is without any ballast inside could test different size and wattage of LED tubes or T8-T5 fluorescent adaptors.

7, LOAD1 and LOAD2 have E27 base and multi-use sockets. It could test any bulbs or electrical products with power plug, and no need to connect the wire in additional.

8,It have different socket converters ,such as E14,B15,B22,GU10,G9. So it can test different lamps with different base.

9,With terminal holders, it could test any electrical products with wire.

10,With fuse inside the power sockets, it could protect the over load short circuit.

11,Compact size, small volume, very light , convenient to carry.

Best after sales-services of our LED tube tester

With 1 year warranty if non-human reason error, free of charge replacement is available.
