Single Phase Multi-Functional Energy Meter (DDS1088)

OVERVIEW

DDS1088 Single-phase multi-functional meter is mainly designed for the metering demands such as energy consumption, maximum demand and event record, etc.
It use remote infrared communication method for meter reading and monitoring as well as parameter setting.
The meter complies with IEC 62053-21, IEC62053-23 and IEC62056-21.

FEATURES

1. Total active power consumption measurement. (Absolute mode)
2. Total reactive power consumption measurement. (Absolute mode)
3. Tariff active power consumption measurement.
4. Tariff reactive power consumption measurement.
5. Two elements.
6. LCD display.
7. Infrared and RS485.
8. RTC.
9. State indication.
9.1. Current quadrants.
9.2. Real time metering voltage, current, active power, reactive power, apparent power, power factor and frequency.
10. Events record
10.1. Record with date and time of the latest 10 records case opening events and total opening times.
10.2. Record with date and time of the latest 10 records power on/off events and total power off times/hours.
10.3. Record with date and time of the latest 10 records demand clear events and total clear times.
11. Can store latest 12 months data, configurable billing date and time.
12. Measures reactive maximum demand and demand interval, configurable slide time.
