Rg-11 Coaxial Cable 1.63mm CCS Conductor High Conductivity

RG-11 Coaxial Cables

Application:

Used in cable TV operations, Computer net-working etc.

Construction:

Solid annealed bare copper conductor polythelene insulated shielded with polyester backed aluminium tape and additional shielding with fine aluminium braid protected with polyester tape wrapping and sheathed with PVC.

Specifications:
1)1.63mm Solid Bare Copper +7.11mm Foamed PE +Bonded AL Tape+60% AL Braid+ 10.00mm PVC
2) Customers' specifications are welcomed.
Note:
1) Center conductor: Tinned Copper, Bare Copper, and Copper Clad Steel available;
2) Al-foil: Non-bonded Al-foil, bonded Al-foil, double bonded Al-foil, And double non-bonded Al-foil are available;
3) Braiding wire: AL, Bare Copper and Tinned Copper available;
4) Braiding wire diameter: 0.10, 0.12, 0.13, 0.14, 0.15, 0.16mm available;
5) Braiding net: 32, 48, 64, 72, 80, 96, 120, 128, 144 and more available;
6) Braiding coverage: Between 30- 97% available;
7) PVC jacket of Flame retardant, UV, or UL available.
Characteristics:
Impedance(phm): 75

Velocity Ration(%): 85
Capacitance(pF/mttr): 53

Return Loss(dB/100m): 30-300MHz >26

300-550MHz >24

Bending Radius, min(mm) 75

Packing:
1) Packing Lengths:
100m/roll, 200m/roll, 305m/roll, 100yard/roll, 200yard/roll, 300yard/roll
Other lengths available according to client's request;
2) Inner packing: Wooden reel, plastic reel, and paper reel available.
3) Outer packing: Carton box, pull out box, pallet available.
4) Other packing available according to client's request.

Supplied in 90 meters&305 meters project packaging.
