Electronic Potting Silicone

Quick Details

Place of Origin: China (Mainland) Brand Name: Hongye silicone rubber HS code: 39100000 Certification: MSDS, ROHS,SGS Sample: available Specifications

Features & Applications

PCB Electronic Potting Silicone Rubber with black color is in two parts with low viscosity.

PCB Electronic Potting Silicone Rubber with black color can be cured completely at room temprature.

PCB Electronic Potting Silicone Rubber with black color works on the surface of material as PC(Poly-carbonate), PP, ABS, PVC as to its superior bonding feature.

PCB Electronic Potting Silicone Rubber with black color is also applicable for insulation, waterproof and bonding of electronics parts.

PCB Electronic Potting Silicone Rubber with black color meets the requirements of European RoHs.

Typical Application

-Potting for Protection of general electronic module.

-Outdoor protection for LED screen.

(Pls note all data of PCB Electronic Potting Silicone Rubber with black color above is in 25C with 55% humidity conditions. We don' t guarantee a same date if testing under different conditions, or when data was regenerated).

Warm Tips

1. Sealing pakage for storage. The mixture should be used up at once to avoid wasting.

2. Silicone belongs to non-dangerous goods, but keep away form mouth and eyes.

3. When it gets stratified after a period of storage, Please mix HY-210# evenly before using,

it does not affect the performance.

Package

22kg/set (Part A 20kg + Part B 2kg)

Shelf Life and Transportation

1. Twelve(12) months when stored at 25C in original unopened packages.

2. This is a non-dangerous product, it can be transported as general chemicals.

3. Products exceed the storage life should be confirmed normal before using.

Technical Guidelines

1. Pls put part A and B in separate container and stir evenly before mixing the two

parts together.

2. Mixing Ratio part A: part B is 10:1

3. Bubble release if necessary, deaeration the mixture under 0.08 MPa for 3 minutes.

4. HY-215# is cured at roon temperature, so pls put it under room temperature after

pouring. It comes to next process when basically cured, and it takes about 24 hours

for completely cured.
