obd2repair A Quality 2013 03 CDP Plus Bluetooth Auto CDP plus single PCB

A Quality CDP Plus is designed like original cdp+. 2013.3 CDP Plus Bluetooth with free cdp delphi 2013.3 keygen activator. Auto CDP+ single PCB support all Cars & trucks in software

A Quality 2013.3 CDP Plus Bluetooth Auto CDP+ single PCB

Single PCB board 2013.3 Auto CDP plus with Bluetooth function for all Cars & trucks in software

Bluetooth CDP+ support Languages: English, Cesky, Dansk, Deutsch, Espanol, Francais, Greek, Hollands, Hungarian, Italiano, Norsk, Polish, Romania, Russian Srpski, Suomen kieli, Svenska, Turkish.

Simply connect Auto CDP+ VCI to the diagnostic socket in the vehicle and it will communicate with the diagnostic software installed on your PC.

Auto CDP+ New VCI is a Vehicle diagnostic tool used with a PC or Pocket PC, Auto CDP+ is a powerful and flexible tool for all vehicle shops, fleet owners, vehicle testing, road service, police and armed forces. Auto CDP+ Vew VCI is a quick and reliable diagnostic tool serving as a link between vehicle and computer. It works on both old and new vehicles.

Bluetooth CDP+ Vehicle coverage: For cars and light vans from 1988 onwards, a total of 47 different brands. For light and heavy commercial vehicles, buses and trailers from 1995 onwards, a total of 37 different brands.

Flight recorder of cdp+

With the flight recorder function of Auto com CDP plus, you can record parameters in real time while you are driving a vehicle. During flight recording, you can, with a press of a button, highlight the specific error so that you can investigate the detected error at a later time. Car Diagnotic Tool Auto com CDP+ is equipped with built-in memory thus removing the need to bring a computer.

To create a Flight Recorder session, you will first need to select the parameters/real time data that you want to record. You start by opening the customised data list in the real time data menu in the diagnostic program. You can choose to create a session for all system types (Engine, ABS, AC etc.), but only for one system at a time, as the vehicle can´t communicate with multiple systems at the same time. When you have selected the parameters, they will be tested on the vehicle to verify that they are valid data. Your parameter selections are then transferred to Autocom CDP+ and a Flight Recorder session is created. Previously recorded data and templates are deleted upon creation of the new session. You can then disconnect Auto com CDP+ from the computer and vehicle, and start the Flight Recorder when you are test driving the vehicle. Multiple sessions/recordings can be saved on Auto com CDP+ and you can select the sessions you want to upload and save on your computer.

DURING TEST DRIVE Of Flight Recorder

Start a new session by pressing and holding the button on Auto com CDP+ until the indicator turns yellow and CDP+ makes a short audible tone. The yellow light then starts to rotate to indicate that data is being recorded. To easily find the part of the data where the symptom occurred you can earmark symptoms in the session. To do this, briefly press the Flight Recorder button.

CDP+ Flight Recording BENEFITS

You don´t need a computer while testing, Makes localisation of intermittent faults easier, Clear audio and visual signals, You can record data over long periods of time

* MULTI COLOUR INDICATOR. With the multi colour indicator on Auto CDP+, you have full control of the diagnostic process. Different colors and sound communicates the status and the placement of the indicator allows you to see it from a far. For example, if the indicator alternates between blue and green the Auto CDP+ is in communication with the vehicle control unit

* CONNECTOR WITH LED. To locate the diagnostic connector in the vehicle with ease, even if it's located in a dark and inaccessible place, there is a LED on the 16 -pin connector to help you along. The location and the design allows the light to function even when using the adaptor cable for vehicles without a 16-pin diagnostic socket.

* VOLTAGE CHECK. When Auto CDP+ is connected to the vehicle, the unit will check the battery voltage of the vehicle and automatically adjusts itself to the vehicle`s voltage level of 12 or 24 volts. If the voltage gets too high or too low, Autocom CDP+ will
warn you with both sound and light and you will also be alerted through the battery icon in our diagnostic software.

* CHASSIS NUMBER VIN. In CDP CARS software, we have a smart function that allows you to read out the chassis number from the vehicle that you would like to diagnose. This ensures that the right model and year is selected automatically. In addition, engine code for vehicles, which are commonly available on the markets, is also selected automatically.

* ISS. Intelligent System Scan (ISS) scans through all the systems in the vehicle and displays the fault codes that are stored in each system. This saves time and you get a quick overview of the actual status of the entire vehicle. When the ISS is complete, you can then select a specific control system to analyse the results further on.

* ISI. Intelligent System Identification (ISI) identifies and selects automatically the type of controller that is mounted in the vehicle. This ensures that the diagnostic session is performed correctly with the correct parameters as required.

* REPORT FUNCTION. Under this function tab, you will be able to see the adaptations and adjustments that are possible for a specific vehicle without having the vehicle near you. Together with the help texts as a guide, you can plan and be effective in your work; even under complex situations.

* OBD-FUNCTIONS. Auto COM CDP+ is equipped with an unique multiplexer technology, which allows it to be used on all types of vehicles, regardless of voltage levels and communication standards. For those vehicles that do not use the standard 16-pin connector, we offer a complete set of certified and customized adapter cables and kits.

* UNIVERSAL. For most OBD functions, such as adjustments and programmings, there are detailed instructions and help texts to assist you in your diagnosis work. You will find step by step information about prerequisites, preparation and implementation of various functions; making even the most complex function simple to perform.

* HELP FUNCTION. For most OBD functions of Auto Com CDP, such as adjustments and programmings, there are detailed instructions and help texts to assist you in your diagnosis work. You will find step by step information about prerequisites, preparation and implementation of various functions; making even the most complex function simple to perform.

AUTO CDP + Package

1pc x AUTO CDP plus with OBD2 cable
1pc x USB Cable (Autocom CDP)
1pc x 2013 release 3 CDP+ Diagnostic software
