Automatic TIG/ MIG Straight and Longitudinal Seam Welding M

LW-800mm Automatic TIG/MIG Straight (Longitudinal) Seam Welding Machine, Maximum welding length up to 800m

1. Main features

● Automatic Straight Longitudinal Seam Welding Machine mainly includes two parts: specially designed straight seam automatic machinery part and standard welding source part

● Standard welding source part includes TIG (tungsten inert gas shielded arc welding), MIG(metal inert gas shielded arc welding), MAG (metal active gas arc welding) SAW(submerged arc welding), PAW(plasma arc welding) etc. Automatic machinery part can be equipped by the standard welding source manufactured by our company , can also work with other well-known brands of welding power

● Automatic machinery part is adopted PLC control, DC motor drive has stepless adjustable welding speed and interfaces with any power source

● Weld seam back up design has a groove to form a weld on the bottom of a welded plate and provide consistent gas flow to the back of the weld, to assure the stable gas shield and ensure double-side forming in single side welding

● Automatic straight longitudinal seam welding machine is mainly used for the high quality and low distortion automatic straight welding, such as metallic cylinders and aligned plates made with stainless steel, iron, aluminum and brass etc.

● Compared with the traditional manual welding way, high welding efficiency and speed, well welding quality and good consistency

2. Technical parameter
