Mesh Led Curtain Display for Network Remote Centralized Con
  • Mesh Led Curtain Display for Network Remote Centralized Con
Mesh Led Curtain Display for Network Remote Centralized Con

Mesh Led Curtain Display for Network Remote Centralized Con

Min. Order:
1
Min. Order:
1
Delivery Time:
30 Days
Quantity:

Your message must be between 20 to 2000 characters

Contact Now
Basic Info
Basic Info
Place of Origin: Shenzhen China
Product Description
Product Description

Mesh Led Curtain Display for Network Remote Centralized Controlling 1R1G1B P37.5

Description:
Mesh LED signs is so classic among all styles of LED signs that the weight is 7kg with the size of 0.6mX0.6m, the maximum thickness is 80mm, and the permeation ratio is up to 40%. The special design features of the screens express the unique artistic charm, such as lightness, thinness and so on. The figurative image displayed by Stage background LED signs is like oil painting, the perspective effect just like the fairy land, and the abstract scenes build the dreamlike atmosphere.
Function:
video broadcasting,
information publishing,
network remote centralized controlling.
Specification:

Product model number

RH-FS-P37.5

1. Pixel

Pixel LED

SMD 5050

Pixel configuration

1R, 1G, 1B

Wave length(nm)

R: 626-628, G: 518-520, B: 466-468

Pixels pitch(mm)

37.5

2. Module

Module size(mm)

1200* 300 * 11.5

Module resolution(pixel)

32 * 8

3. Electricity parameter

Physical pixel density(pixels/m2)

711

White balance brightness(nit)

≥1000

Color temperature(K)

5000—9500 (choice by user)

Brightness adjusted

100 grade by software, or by Auto-optic induced

View angle

110°

Best viewing distance(m)

>37.5

Communication distance(m)

Internet Wire:120 Fiber Cable: 1000

Screen work method

1/1

LED driving method

Constant driving current

Gray grades

16384 levels for each color

Display color

4.4 trillion

Refresh frequency (Hz)

≥ 120

Signal interface

DVI

Input signal

Video:PAL/NTSC:optioned.VGA, Svideo, DVD, TV

Display format

800 * 600, 1024 * 768, 1280*1024

Software

Support windows series system

Protection grades

IP65

Working temperature(ºC)

-20 ~ +60

Humidity(RH)

10 – 95%

Stored temperature (ºC)

-30 ~ +70

Screen lifetime(hours)

≥100, 000

Out of controlled dots

≤3/10, 000 (Out of controlled dots means the dots of which the brightness
and the wave length are both >10% depart to the normal one)

Whole display flatness

Less than 1mm Juncture

Maintenance way

Back-maintained, modules displaced

Switch power supply

Single Phase AC: 110V/60Hz or 220V/50Hz

Power consumption (w/m2 )

Max:400, Average: ≥125


Competitive Advantage:
1, Good quality;
2, Good price;
3, Good 24hours service;
4, Promote delivery;
5, Energy-saving;
6, Small order accepted.
