Electric 50HZ 400W / 800W Pure Sine Wave Inverter Solar Pow
- Min. Order:
- 1
- Min. Order:
- 1
- Delivery Time:
- 30 Days
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | China |
|---|
DIV Series Telecom and Electric Solar Power Inverter 220% Overload 50HZ
Quick Detail:
- Pure Sine wave output DC voltage: 12/24/48/110/220V
- AC output: 220/230/240V, 50/60HZ
- pure sine wave Inverter
- actual demand for Electrical power system and Telecom system
- the influence of noise on office or data center staff
Specifications:
|
Technical Specifications |
500VA |
1000VA |
2000VA |
3000VA |
4000VA |
5000VA |
6000VA |
|
|
DC INPUT |
Input Voltage(Vdc) |
12/24/48/110/220V |
||||||
|
Reverse Noise Current |
≤10% |
|||||||
|
AC Bypass |
Bypass Volt(Vac) |
265V-185V(±10V) |
||||||
|
Input Current(A) |
2.3 |
4.5 |
9.1 |
13.6 |
18.2 |
22.7 |
27.3 |
|
|
Transfer Time(ms) |
≤5ms |
|||||||
|
AC OUTPUT |
Rated Capacity(VA) |
500VA |
1000VA |
2000VA |
3000VA |
4000VA |
5000VA |
6000VA |
|
Output Power(W) |
400W |
800W |
1600W |
2400W |
3200W |
3500W |
4200W |
|
|
Voltage and Frequency |
220Vac,50HZ |
|||||||
|
Output Current(A) |
1.8 |
3.6 |
7.2 |
10.8 |
14.5 |
16 |
19.1 |
|
|
Voltage Precision(V) |
220±1.5% |
|||||||
|
Frequency Precision(Hz) |
50±0.1% |
|||||||
|
Output |
Pure Sine Wave |
|||||||
|
Wave Distortion(THD) (Resistant Load) |
≤3% |
|||||||
|
Dynamic Reaction Time (Load 0←→100%) |
5% |
|||||||
|
Power Factor(PF) |
0.8/0.7/0.6 |
|||||||
|
Overload |
220%,30 sec |
|||||||
|
Inversion Efficiency (80% Resistant Load) |
≥85% |
|||||||
|
Transfer Time(ms) |
≤5ms |
|||||||
|
ENVIRONMENT |
Isolation(IN/OUT) |
1500Vac,1minute |
||||||
|
Noise(1m) |
≤40dB |
|||||||
|
Temperature |
-25℃~+50℃ |
|||||||
|
Humidity |
0~90% |
|||||||
|
Sea Level(m) |
≤2000 |
|||||||
|
SHOW |
LCD |
Input/output voltage, frequency, output current, temperature |
||||||
|
LED |
line,inverter,battery,Output Load |
|||||||
|
19 Inch Rack Type (D×W×H)(mm) |
360x448x88(DIV 24-1KVA;DIV48-1KVA/2KVA; DIV110-1KVA/2KVA; DIV220-1KVA/2KVA) 390x448x88 (DIV24-2KVA/3KVA/4KVA/5KVA/6KVA) |
|||||||
|
Weight(Kg) |
7KG(1KVA);8KG(2KVA);11KG(3KVA);12KG(4KVA);13KG(5KVA);14KG(6KVA) |
|||||||
|
Protection Function |
Input Low/High Voltage;Output Overload/Shortage; Connecting Protection |
|||||||
- With the excellent designing, DIV series inverter can be auto switched to bypass on the running state, it’s easy to maintain and replace the battery without effecting load power supply.
- In case there is battery voltage high/low or overload, the overload warning shutdown output, when battery voltage recovers normal, battery voltage recovers; power supply output will auto recovers in 50 seconds after overload off. This function is very suitable for the communication station in which there is no person on duty.
- DIV series inverter can support network communication system, power working state can be monitored by the supervision software.
- DIV series inverter provides with two dry connectors which can be used for DC input fault checking and AC output problem warning.
- With micro-CPU control, DIV Series inverter is an intelligence model product, good designing and reliability are the advantages.
- DIV series inverter is adopting SPWM technology, with the output of stabilized voltage and frequency, pure sine-wave.
- DIV series inverter has good compatibility, built-in by-pass switch, high overload feature for reliable and continuous power supply.
- DIV series inverter can be AC power type and DC power type:
- AC power type means the city power supply is main when the city power is normal, when city power is off, inverter comes into work state.
- DC power type means the inverter power supply is main when the city power is normal, when inverter power is off, city power comes into work state automatically.
