Full-automatic four-shaft CE BOPP Packaging Tape Slitting Machines
1. To slit bopp packing tape
2. min. slit 10mm
3. max. work width: 1620mm
4. CE



FR-210 BOPP Packaging Tape Slitting Machine

Feature

1. Full-automatic four-shaft exchange is adopted and the efficiency is improved.

2. Stepless speed regulation of frequency conversion and three-step length setting provide smooth rewinding operation to ensure accurate rewinding length. It can automatically decelerate and stall when operating at high speed.

3. The unwinding tension is adopted with pneumatic braking control. The rewinding tension is adopted with the dual control equipped with the clutch and the independent slide setting for free adjustment of the tensile force.

4. The curved stretch roller is designed to eliminate tape wrinkling during extension and feeding.

5. Pneumatic brake brings the machine to an immediate halt for accurate positioning and labeling.

6. (Optional) Auto labeling and slitting stationery tape functions.


Main Technical Parameters

model

FR210-1300

FR210-1600

Effective width

1320 mm

1620 mm

max. unwind diameter

800mm

800mm

min. slitting width

12mm

12mm

max. rewind diameter(shaft1") exchange 4 shafts

75mm

75mm

max. rewind diameter(shaft3") exchange 4 shafts

150mm

150mm

max. rewind diameter(shaft3") exchange 2 shafts

300mm

300mm

machine speed

0-180m/min

0-180m/min

slitting blade

0.2×22×60mm

0.2×22×60mm

main power

5.5KW

5.5KW
