Warm White 3300K 10 W Outside Led Flood Lights CRI > 80 Epistar LED
Quick Detail:
- Item Number: XBFL001-10W
- Power Supply Brand: shenzhen driver
- Type: LED Flood Lights
- Lamp Power (W): 10w
- LED Quantity: 1PC
- Input Voltage (V): AC85-265V / 50Hz—60Hz
- Produce Size: L115*W85*H70mm
- Inner Box Size: L118*W89*H93mm (1PC/Inner Box)
- Carton Box Size: 470*255*49mm(50PCS/Carton Box)
Description:
Tempered Glass Cover
Made of proessional optical materials, the glass visible light transmittance is more than 96%, the surface reflected light decreased is less of 2%, hardness>+7H; temperature resistance: +200℃-40℃
Heat Sink
Adopt high-quality and thickness die-casting aluminum housing for heat dissipation, fin heat sink on the back to enlarge the area of longer lifespan of the lamp, grey and black color heat sink for option.
LED Chip
Adopt Epistar 45mil COB led chip, large diameter double core to let big current going through, stable working, super brightness, low light fades and long lifespan.
Power Suppiler
Adopt isolated constant current driver with wide working voltage 85-265v, stable working and safety, used imported components, better in quality, longer lifespan
Applications:
Large-scale operations in mining, building outline, the stadium, overpasses, monuments, parks , flower beds and other outdoor lamps and lanterns.
Specifications :
| Item Number | XBFL001-10W | |
| Power Factor | 0.95 | |
| Power Efficiency | ＞95% | |
| Total Harmonic Distortion | ≤20% | |
| LED Sources | Epistar LED Chip | |
| LED Power Consumption | 10w | |
| Total Power Consumption | 12w | |
| Lampshade Degree | 90/120 | |
| Luminous efficiency | >90lm/w(bare LED) | |
| Luminous Flux | >900lm | |
| Light Distribution | Symmetrical/Round Light Spot | |
| Light Design | LED+reflector | |
| LED Junction Temperature | ≤80℃ | |
| WorkingTemperature | -40℃~+45℃ | |
| IP rating | IP42 | |
| Lifetime | >50000Hrs | |
| Power line | 0.75mm² three-core wire | |
| Wires | L: live wire | |
| N: neutral wire | ||
| E: Earth wire | ||
| Color | Cool white / Warm white / Natural white / Pure White/ Red / Green /Blue /Yellow | |
| Color Temperature | Warm White | 2700-3200K |
| Pure White | 6000-6500K | |
| Cool White | 10000-12000K | |
| Color render index | Warm White | Ra＞85 |
| Pure/Cool White | Ra>75 | |
| LED initial luminous flux | Warm White | 4350±3%lm |
| Pure White | 4500±3%lm | |
| Cool White | 4450±3%lm | |
| Color of Housing | Black and grey | |
| Warranty | 3Years | |
| Certifications | CE,ROHS | |
Competitive advantages:
Quality +safety,The lamp bead is encapsulate by us. Quality guaranteed and reasonable price,also good heat dissipation function ,foot wattage.
