Portable Outdoor 1 / 3 CMOS CCTV Mini Camera wireless 520TVL 12V DC
Quick Detail:
1. Model Number: ZBS900-12
2. Brand Name: ZHIBOSEN
3. Type: CCTV Mini camera
4. Imaging device: 1/3 CMOS
5. System format: PAL or NTSC
6. View angle: 55 degrees
6. Pixel: 520TVL
7. Place of Origin: Guangdong China
8. Gross Weight: 0.5kg
9. Package Size: 13x8x7cm
Description:
2. 0.008lux for excellent night vision.
3. Ultra small size.
4. Can be used at FPV.
5. Both NTSC/PAL.
Applications:
Use for Home and Business Security, Shops, Pubs and Restaurants, Building Sites, Warehouses, Boats, Marine Use, Sports use, Wildlife, Farms, Stables and Kennels, Surveillance and Covert use, Nursery and child care, Firearm.
Specifications :
| ICK UP ELEMENT | Single chip 1/3 CMOS | |
| SYSTEM | NTSC | PAL |
| NUMBER OF PIXEL | NTSC:656(H)×492(V) | PAL:786(H)×576(V) |
| IMAGE SIGNAL PROCESS | Digital Signal Processing System | |
| SENSOR DIMENSION | 4.75mm(H)×3.55mm(V) | |
| HORIZONTAL RESOLUTION | Approximately 520TV Lines | |
| SCANNING SYSTEM | 2:1 Interlace | |
| SENSITIVITY | 0.008Lux/F1.2 | |
| LENS & VIEW ANGLE | 0.5mm F2.0 /55 ° | |
| S/N RATIO | 52dB | |
| ELECTRONIC SHUTTER | OUT (1/60 S TO 1/100000 S) | OUT (1/50 S TO 1/100000)S |
| AUTO GAIN CONTROL | OUT | |
| WHITE BALANCE CONTROL | OUT | |
| BACK LIGHT COMPENSATION | OUT | |
| VIDEO OUT | 1.0V p-p/75ohm | |
| SIZE (L x W x H) | 9.5X9.5X16mm | |
| WEIGHT | 2g | |
| WORK CURRENT | 70mA | |
| POWER REQUIREMENT | DC 6-24V | |
| OPERATING TEMPERATURE | - 10° C ~ +50°C ,less than 90% RH | |
| Connection | PIN1à Red DC5V PIN2à Black GND PIN3à Yellow VIDEO OUT | |
Competitive advantages:
good price, reliable quality, guarantee of delivery,good services
