Ultra Slim P12.5 SMD 3528 3 In 1 Flexible Led Curtain Displ

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	Shenzhen, China

Product Description

Ultra Slim P12.5 SMD 3528 3 In 1 Flexible Led Curtain Display For Video Broadcasting

Specifications:

Item NO	Teeho-P12.5
LED chip	Taiwan chip
Pixel pitch (mm)	12.5mm
Cabinet size (mm)	400×800 ×48mm
panel resolution	32 x 64
Pixel configuration	SMD 3 in 1
Density of pixel(dot/ panel)	4608
Density of pixel(dot/ m2)	6400
Transparent Rate	40%
Pixel Out-of-control Rate	＜0.0002
Weight / Unit	6.1 kg / panel
Max power consumption (W/ panel)	200
Max power consumption (W/ ㎡)	≤250W/㎡
Color temperature	5000 K
View distance	> 10 M
Luminance(CD/ m2)	850 cd / sq.m .(adjustable)
Panel Structure	Aluminum (Corrosion Resistance)
Frame Rate	50-60Hz
Power Supply	AC 90V -- 260V, 50 -- 60HZ
Working Voltage	DC 5V
Best viewing angle	Horizontal120°, vertical 120°
Colors	16.7M
Control system	Online control, based on PC
LED Drive	1/6
Life-span	＞50, 000 hours
Protect leve	IP43/54(optional)
Rigging System	aluminum hanging tube (manually-handleable, quick- lock design)
Working environment	Instore:-40~+80℃, Work:20~+50℃
Relative Humidity	10%~90%RH
Control Mode	Special Video Controller
Signal Communication (Regular)	S-Video, HDMI, DVI, VGA, CVBS, Y/PB/PR
Warranty	1 year
