high quality rj11 coaxial cable
Your message must be between 20 to 2000 characters
Contact NowBasic Specification
| Inner conductor | CCA/CCS/CU |
|---|---|
| Dielectric | SPE/FPE |
| Model Number | RJ11 Coaxial Cable |
| Type | Coaxial |
| Optional Color | ed/white/grey/black/blue/geen |
| Length | other |
| Type | Other |
Detail Description
RJ 11 Specification
1) Inner conductor: CCA/CCS/CU
2) Dielectric: SPE/FPE
3) AL Foil: Bonded, non-bonded, single, double
4) Braiding wire material: Cu, Al-Mg, TC
5) Braiding wire diameter: 0.12mm, 0.15mm, 0.16mm
6) Braiding net: 48,64,72,80,96,128 and more
7) Coverage: 40%,50%, 60%, 80% and more
8) PVC Degree: 65,68,70,75
9) Messenger: Steel
10) Color: Black, white or grey
11) OEM and client’ designation are welcome
12)Specification for your reference: 1.63CCS+7.11FPE+AL FOIL+96*0.12Braiding+10.03PVC
13) We are in the field of all kinds of coaxial cable:
RG6 Coaxial CATV Cable,RG6 Tri, RG6 Quad, RG6 Messenger
RG6 Spec: 1.02CCS+4.57FPE+AL Foil+60%Braid+6.9PVC
RG6 Semi-finished RG6 Coaxial Cable:
1.02mm BC or CCS+4.60 mm FPE + Bonded Al Foil+16*4*0.16mm 67% AL-mg
Packing:4000m/drum, 4200m/drum with pallet
RG59 CCTV Cable,Composite Cable RG59+2C/18AWG Power
RG59 Spec: 0.81BC+3.7SPE+AL Foil+60%Braid+6.10PVC
RG11 Drop Coaxial Cable,RG11 Tri, RG11 Quad,RG11 Messenger wire
RG11 Spec: 1.63CCS+7.11FPE+AL Foil+90%Braid+10.30PVC
Trunk Cable Coaxial QR540 QR500 QR412:
RG500 cable coaxial: 2.77CCA+11.5FPE+ALTube+14.50mmPE, PVC, +2.77Steel Messenger
CCTV Cable Coaxial RG58 RG8 RG213 RG174 RG179 LMR195 200 300 400,D-FB Cable,C-FB,C-2V,KX / CT/ SAT/ VATC Cable
Cable coaxial RG58:19* 0.18mmCU or TC +2.95mmSPE +95% BC, TC Braiding + 4.95mmPVC Cable coaxial
Coaxial CCTV Cable RG213: 7*0.75mmCU or TC +7.24mmSPE +95% BC or TC +10.30PVC
Additional Information
| Payment Terms | L/C, T/T |
|---|---|
| Minimum Order | 600box, 305m/box |
| Lead Time / Delivery Time | 25 Day(s) |
| Sample Available | YES |
| Delivery Details | Terms of Payment: T/T 30% deposit upon order, 70% payment before shipment |
| FOB Port | Shenzhen |
| Loading Info | Contact me |
| Packing Info | Contact me |
| Target Market(s) | Africa(except Middle East), Eastern Europe, Hong Kong/ Macao/ Taiwan, Japan & Korea, Latin America, Mainland China, Middle East, North America, Northern Europe, Oceania, Central & Southern Asia, Southeast Asia, Western & Southern Europe |
