M200 High-performance general purpose vector variable frequency drive

         M200 is launched by Shenzhen Easydrive Electric Co.,Ltd. It is high-performance general vector frequency inverter, adopting motor control dedicated chip—DSP digital signal processor. Core algorithm uses advanced Magnetic field orientation vector control algorithm to finish motor decoupling control. It has the capacity of high start torque at low frequency , accurate control and high-speed dynamic responsiveness.

PRODUCT FEATURES

1,V/F control mode (One inverter control more than one motor---- 3motors most)

A,Advanced vector control algorithm , optimized SVPWM output , low harmonic output, low motor temperature rise.

B,Realize most optimized energy-saving running by detecting motor parameters.

2,Open-loop vector control mode

A,Adopt T1 high-speed motor control special processor---DSP and finish complicated vector computation high-speedily and exactly to realize motor complete decoupling.

B,Advanced algorithm ,150% rated torque output at 0.5Hz, 0.5% stable speed accuracy, 1:100 adjustment speed range .

3,Simple PLC can realize 16 speeds control

4,Built-in PID can compose close-loop control system conveniently. It is suitable for process-control system, like pressure and flow and etc.

5,Standard RS485 port supports MODBUS communication protocol, can compose a net to communicate with host controller, like touch panel , PLC and etc.

6,Sophisticated protection

It can realize about 20 kinds of faulted protection, such as over-pressure, under voltage, input phase lack, output phase lack, over-load, over-heat, over-current, external terminal fault, communication fault, current detection fault, motor tune fault and etc. The reliability is higher.
