cnc polyurethane foam machine 8STC-1325HX
Quantity:
Your message must be between 20 to 2000 characters
Contact NowBasic Info
Basic Info
Product Description
Product Description
Basic Specification
| polyurethane foam machine | polyurethane foam machine |
|---|
Detail Description
Description of high quality styrofoam food container machine 8STC-1325HX
1. Industry:
Styrofoam mold,wood mold,large plastic molds,large casting mold,mold shade,landscape dies mold,and other major figures.
2. Parameter of high quality styrofoam food container machine 8STC-1325HX
3.factory
4.1 Payment terms
pls kindly contact us:
Contact:Alexus Ping
Tel:+86-755-29026698
Fax:+86-755-29023383
Mobile:+86-13528817241
Add: NO54,Junxin Road, Guanlan Town, Baoan District,Shenzhen,China.
1. Industry:
Styrofoam mold,wood mold,large plastic molds,large casting mold,mold shade,landscape dies mold,and other major figures.
2. Parameter of high quality styrofoam food container machine 8STC-1325HX
| Machine Model | 8STC-1325HX |
| Platform size | 1600x3100mm |
| Working range | 1300x2500mm |
| Z-axis range | 550mm |
| Max Height of material | 750mm |
| Machine Structure | 8mm thick heavy-duty tubular steel frame,full-welded,VSR |
| Surface material | Thickend aluminum |
| Fixturing method | T-slot for clamp fixture |
| X,Y Transmission | Germany Slanting rack |
| Z-axis Transmission | HIWIN 25 Ball Screw |
| Rail configuration | HIWIN 25 Square guide rail |
| Positioning accuracy | ±0.1/300mm |
| Spindle speed | 0-24000(r/min) |
| Y-axis dual drive | Stepper Motor LeiSai 110,Shenzhen |
| X,Z axis drive | Stepper Motor LeiSai 110,Shenzhen |
| Control System | NcStudion Control System of Shanghai |
| Code Formats | G code,U00,mmg, nc |
| Idle speed | 0-20000mm/Minute |
| Working speed | 0-15000mm/Minuter |
| Resolution | 0.00625/Minute |
| Tool diameter | 3.175mm,4mm,6mm,8mm,10mm,12.7mm |
| Spindle power | 4.5kw |
| Cooling System | Water cooling |
| Weight | 3100KGS |
| Power | 380V50HZ±10(Internal Power) |
| Electric Box | Intergrated computer control cabinet |
| Mode of motion | Grantry moving |
4.1 Payment terms
T/T : 30% deposit,70% balance
Western Union
L/C:
4.2 Custom Services
If you are urgent about the machines, please leave your workable telephone number or add me on Skype. My Skype ID is: naik.sales11. You can leave your message of this product you\'re seeing, and send us inquiries at the bottom of product introduction\"Message\'blank box\" .We will reply you any questions soonest !pls kindly contact us:
Contact:Alexus Ping
Tel:+86-755-29026698
Fax:+86-755-29023383
Mobile:+86-13528817241
Add: NO54,Junxin Road, Guanlan Town, Baoan District,Shenzhen,China.
Additional Information
| Payment Terms | L/C, T/T, D/A, D/P, Credit Card, Western Union, Money Order, Paypal, Others |
|---|---|
| Minimum Order | 1 |
| Lead Time / Delivery Time | 20 Day(s) |
| Sample Available | YES |
| Delivery Details | depends on you |
| FOB Port | Shenzhen |
| Loading Info | depends on you |
| Packing Info | Inner package: plastic filmOutside package;wood case |
| Target Market(s) | North America, Oceania, Southeast Asia, Eastern Europe, Africa(except Middle East), Hong Kong/ Macao/ Taiwan, Latin America, Japan & Korea, Middle East & South Asia, Mainland China, Western & Southern Europe, Northern Europe, Central & Southern Asia, Middle East |
