CNC plasma cutting machine CNC gantry plasma cutting machine
Quantity:
Your message must be between 20 to 2000 characters
Contact NowBasic Info
Basic Info
Product Description
Product Description
Basic Specification
| processing area | 1500*3000mm |
|---|---|
| Working material | Iron,aluminum,titanium,stainless steel |
| working thickness | 0.3~12mm |
| plasma power | 65A |
| Plasma generator | USA Hypertherm plasm |
| Accuracy | ±0.1/300mm |
| Power | Hypertherm plasma source |
| Raw Matirel | SS Carbon Steel Plate |
| Voltage | 380V |
| Size | 1500*3000mm |
Detail Description
CNC plasma cutting machine CNC gantry plasma cutting machine
| Platform Size (mm) | 1700mm* 3400mm |
| Engraving range (mm) | 1500mm* 3000mm |
| Structure options | Casting steel struture |
| Platform material | Iron& steel |
| Table fixed type | Electrode pressure switch |
| X Axis structure | gear rack |
| Y Axis structure | gear rack |
| Z Axis structure | Air cylinder |
| Z axis feeding height(mm) | 180mm |
| Working Voltage | 380V 50Hz |
| Plasma power option | 65A, USA Hypertherm plasma |
| Plasma cutting gun | USA Hypertherm cutting gun |
| Moving type of cutting gun | Automatic and Pneumatic |
| Max working speed | 0-10000 mm/ min |
| X Axis Drive motor | LeiSai Stepping moter |
| Y Axis Drive motor | LeiSai Stepping moter |
| Z Axis Drive motor | LeiSai Stepping moter |
| Resolution | 0.0025/ pluse |
| Positioning accuracy | ±0.1/300mm |
| Connecting port | USB interface |
| Control system option | Beijing Start SH-2012AH controlling system |
| Code formats | G code, U00, mmg, nc,EMG |
| Cooling system | Water cooling |
1.One year equipment warranty and maintenance for lifetime
2.Free installation and test before shipping and free training for operators
3.Advice for the solutions best for customers requirements
4.Free training and sample provided
5.Meet CE,FDA,ISO9001 standards
We are Professional CNC Router Manufacturer and with the development of our factory , we are sincerely seeking for Global Agent & Distributor
HK Naik CNC EQUIPMENT GROUP CO.,LIMITED
Attn:Daisy Liew
Mob:+86-13612805703
Email:daisy(at)naikcncrouter.com
Additional Information
| Payment Terms | L/C, T/T, Western Union, Paypal |
|---|---|
| Minimum Order | 1 |
| Lead Time / Delivery Time | 15 Day(s) |
| Sample Available | NO |
| Delivery Details | 7-12 days after payment received, depends on order quantity. |
| FOB Port | Shenzhen |
| Loading Info | 7-12 days after payment received, depends on order quantity. |
| Packing Info | foam box inside and wood box outside. |
| Target Market(s) | Africa(except Middle East), Central & Southern Asia, Eastern Europe, Hong Kong/ Macao/ Taiwan, Japan & Korea, Latin America, Mainland China, Middle East, North America, Northern Europe, Oceania, Southeast Asia, Western & Southern Europe |
