120PCS SMD3020 panel light box for advertising CE&RoHs approval

120PCS SMD3020 panel light box for advertising CE&RoHs approval

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Product Description

Product Details

Basic Specification

Frame material	Aluminum, PMMA
Certification	CE&RoHs approval
Voltage	90-260V
Material	Aluminum, PMMA
Application	Airport, Bedroom, Church, Cinema, Gallery, Garage, Hospital, Hotel, Meeting Room, Museum, Office, Restaurant, School, Shopping Mall, Sitting Room
Light Source	LED

Detail Description

1 Curve aluminum snap frame,easy to change power
2LED light sour
Description:
*Curve aluminum snap frame,easy to change powrer
*Extreme slim,thickness is 18mm only

*Frame Profile 30mm

*LED light source,power saving

*Single side model

*High Quality SMD LED

*DC powe

*Anodized Finishing, can be in different color

*LED lifespan above 80,000hours

*Unique Silknet Printing LGP

*can save more than 80% in power consumption as compared with conventional fluorescent lamp

*Low maintenance

*Suitable for small , middle and big size, customer size is also avaliable

Model NO.	Dimension	Framesize(mm)	Imagesize(mm)	Visualsize(mm)	Voltage	Power	Material	Beam Angle	LED qty/type
MH-LBA4	A4	35727022	238*325	297*210	AC100～240V 50~60Hz	7W	PMMA+ AL6063	120°	120PCS SMD3020
MH-LBA3	A3	48035722	325*448	420*297	AC100～240V 50~60Hz	10W	PMMA+ AL6063	120°	180PCS SMD3020
MH-LBA2	A2	48065422	448*622	594*420	AC100～240V 50~60Hz	14W	PMMA+ AL6063	120°	240PCS SMD3020
MH-LBA1	A1	65490122	622*869	841*594	AC100～240V 50~60Hz	20W	PMMA+ AL6063	120°	336PCS SMD3020

Additional Information

Payment Terms	L/C, T/T, Western Union, Paypal, Others
Minimum Order	4pcs
Lead Time / Delivery Time	5 Day(s)
Sample Available	YES
Delivery Details	by air, sea or international express etc.
FOB Port	Shenzhen
Loading Info	by air, sea or international express etc.
Packing Info	10pcs/ctn 1.6kg/16.5kg 30746556mm (inner carton) 330485580mm (outer carton)
Target Market(s)	Africa(except Middle East), Central & Southern Asia, Eastern Europe, Hong Kong/ Macao/ Taiwan, Japan & Korea, Latin America, Mainland China, Middle East, North America, Northern Europe, Oceania, Southeast Asia, Western & Southern Europe
