Basic Info
Basic Info
Product Description
Product Description
  • Product Details

Basic Specification

hs code 39100000
color any
application Plaster Mold Making Silicones Rubber Compund
appearance liquid material
port shenzhen
Eco-Friendly Yes
Test Report SGS

Detail Description

Plaster Mold Making Silicones Rubber Compund


Plaster Mold Making Silicones Rubber Compund Description :

Plaster Mold Making Silicones Rubber Compund are generally named as two-part addition silicone rubber that vulcanises at room temperature.Part A is a flowable liquid, part B is the curing agent(platinum catalyst). It features an exceptional fluidity ,good operability,excellent physical properties and very low shrinkage. The mixing ratio between Part A and Part B can be 10:1 or 1:1.

Plaster Mold Making Silicones Rubber Compund Main application:

  • Rapid prototyping (urethane casting/silicone tooling/vacuum casting)

  • Concrete moulding

  • PU resin casting

  • General Mouldmaking

  • Superior manual mold designs

  • Cake/Chocolate molds

Plaster Mold Making Silicones Rubber Compund Main properties:

  • almost nil shrinkage

  • high chemical resistance to aggressive components of some types of resins

  • good tear strength (this feature ensures higher resistance to wearing and shearing)

  • high degree of precision in reproduction

  • high dimensional stability over time and  non-deformability

  • high resistance to high temperatures and ageing (resit to -60-200°C)

  • excellent non-stick effect

  • environmental, odorless and nontoxic



Plaster Mold Making Silicones Rubber Compund

(The mixing ratio of part A and part B can be adjusted to 1:1or 10:1)



Product

      E-615

E-620

E-625

E-630

E-642

Appearance

Translucent

 Translucent

Translucent

 Translucent

Translucent

Hardness(shore A)

15±2

20±2

25±2

30±2

42±2

Mix ratio(A:B)

1:1

1:1

1:1

1:1

10:1

Viscocity Part A(mPa.s)

22000±2000

23000±2000

27000±2000

 25000±2000

  55000±2000

Viscocity Part B(mPa.s)

1900±500

1900±500

1800±500

2400±500

150±50

Tensile strength (MPa)

5.2

5.7

6.7

5.5

7.6

Tear-strength  (kN/m)

25

26

23

24

22

Elongation(%)

569

581

480

410

450

Density

1.05

1.05

1.07

1.13

1.14

Pot life/working time (mins)

30-40

30-40

30-40

30-40

30-40

Curing time/setting time (hrs)

  3-4hrs(25°C)

120-30mins(60°C)

3-4hrs(25°C)

120-30mins(60°C)

3-4hrs(25°C)

120-30mins(60°C)

3-4hrs(25°C)

  20-30mins(60°C)

    6-8hrs(25°C)

   130-50mins(60°C)

Shrinkage rate (%)

0.1

0.1

0.1

0.1

0.1

Plaster Mold Making Silicones Rubber Compund Plaster Mold Making Silicones Rubber Compund

Notice:

All above addition silicone is forbidden to mix with organic compounds of condensation cure silicone rubber,otherwise, the silicone rubber will not cure, and also should not mix with organic compounds containing S, P, N as well as metallic salt of organic acids. It also will cause this product cure uncompletely or not cure.



Plaster Mold Making Silicones Rubber Compund Plaster Mold Making Silicones Rubber Compund


Additional Information

Payment Terms L/C, T/T, Western Union
Minimum Order 200kg
Lead Time / Delivery Time 3 Day(s)
Sample Available YES
Delivery Details Within three days after getting your payment
FOB Port Shenzhen
Loading Info FOB Shenzhen port by sea
Packing Info 20kg and 200kg per drum
Target Market(s) North America, Oceania, Southeast Asia, Eastern Europe, Africa(except Middle East), Hong Kong/ Macao/ Taiwan, Latin America, Japan & Korea, Middle East & South Asia, Mainland China, Western & Southern Europe, Northern Europe, Central & Southern Asia, Middle East
