Electronic potting silicone rubber for LED bulb

Typical Application

Electronic potting compound silicone rubber for LED bulb is suitable for bonded seal of electronic components, power module and control module, which requires waterproof and insulation. It can be broadly used for LED screen, Wind Power Generator, PCB substrate, etc.

Description

Electronic potting compound silicone rubber for LED bulb is a newly insulating material silicon of silicon compounds.
It cures without heat, corrosion and just with little shrinkage. It can be applied to the sealing and pouring of various electronic components, and then forming insulation system.

Features

1. No toxicity, solventless, no odor and no cure by-product.
2. Equal amount of mixing ratio, good fluidity, easy processing.
3. No significant exotherm or shrinkage during curing.
4. Flexible curing schedule, can be cured at room temperature (R.T.) or at elevated temperature.
5. Very stable to changes of temperature, stability over wide temperature range (-50 to 200 ^oC).
6. Good fire resistance, UL94V0 approval.
7. Excellent thermal conductivity.
8. Excellent dielectric properties for maintaining and protection of existing electrical insulation requirements.
9. Excellent weather resistance and waterproof property for protection from moisture and dust contamination.
10.Relative easier removal benefits to repair of electrical/electronic devices.

Picture show

Technical Parameters

Precaution

1. Twelve(12) months when stored at 24C in tightly closed original packages.
2. This kind of product is non-dangerous product, which could be transported as general chemicals.
3. Storage beyond the expired date doesnot necessarily mean that the product is no longer usable. In this case however, the properties required for the intended use must be checked for quality assurance reasons

Operation way

1.Put part A and part B in separate container with equal dosage and stir evenly when mixing the two parts together.
2. Put the mixture into the vacuum machine under 0.08 MPa for 5 minutes.
3. The temperature influences the curing time of electronic potting silicone rubber. When in too low temperature, we suggest customers appropriately heat the mixture to accelerate vulcanization.

Certification

ISO9001: HK05/01358
SGS:GZ0606100461/CHEM
RoHS:BTRS091718751
Patent:ZL200520001597.8

Package

20Kg/pail (Part A10Kg + Part B10Kg)
