Silicone Rubber Electronic potting for LED
  • Silicone Rubber Electronic potting for LED
  • Silicone Rubber Electronic potting for LED
  • Silicone Rubber Electronic potting for LED
  • Silicone Rubber Electronic potting for LED
Silicone Rubber Electronic potting for LED
Silicone Rubber Electronic potting for LED
Silicone Rubber Electronic potting for LED
Silicone Rubber Electronic potting for LED

Silicone Rubber Electronic potting for LED

Quantity:

Your message must be between 20 to 2000 characters

Contact Now
Basic Info
Basic Info
Product Description
Product Description
  • Product Details

Basic Specification

application electronic potting compound silicone rubber
operation way by machine or hand
Color Transparent
Appearance Liquid silicone rubber
Mixing ratio 1:1
Eco-Friendly Yes
Test Report SGS

Detail Description

Electronic Potting Silicone Compound (HY-9055#)

Electronic Potting Silicone Compound (HY-9055#) Feature:

LED Silicone Rubber Electronic Material for good elasticity is a kind of low viscosity, Inherent flame resistance, two components addtion cured potting silicone with heat-conducting. It cures with both on room temperature and heated temperature. It has the feature of the higher temperature the faster of the curing time. It can be applied to electronic components for insulation, waterproofing, fixed and flame retardant. It mainly applied in electronic components surface with materials of  PC(Poly-carbonate),PP,ABS,PVC, etc. and metal materials.



Electronic Potting Silicone Compound (HY-9055#) Application:
Electronic Potting Silicone Compound (HY-9055#) could be applied to
- high powered electronics,
- DC/DC module and circuit board which requires heat dissipation and high temperature resistance.
-It can be broadly used for LED screen, Wind Power Generator, PCB substrate, etc.


Potting silicone for LED technical guidelines:
1, Pls put part A and part B in separate container and stir evenly before mixing the two part together.
2, Mixing Ratio: Part A: Part B = 1: 1
3, Deaeration the mixture in vacuum pump under 0.08 MPa for 3-5 minutes. Then the mixture could be used for pouring.
4, Pls note that the thickness of the silicone affects the curing time. If the silicone used is a little thick, then the curing time will be a little longer. The temperature also affects the curing time. When in lower temperature, we suggest customers appropriately heat the mixture to accelerate vulcanization. With temperature of 80~100° C, the silicone will cure in 15 minutes; While in 25° C room temperature, the silicone will cure around 8 hours.


Need any help on silicone rubber, please feel free to contact Hugo:
TEL:086-755-89948019
FAX:086-755-89948030
MOBILE:086-15017635728
SKYPE: hugo.chen007
Website:www(dot)szrl(dot)net
E-MAIL:hugochen014(at)gmail(dot)com


Additional Information

Payment Terms L/C, T/T, Western Union, Paypal
Minimum Order 200kg
Lead Time / Delivery Time 6 Day(s)
Sample Available YES
Delivery Details Within three days after getting your payment
FOB Port Shenzhen
Loading Info FOB Shenzhen port by sea
Packing Info 5kg/drum, 20kg/drum and 200kg/drum Electronic potting compound silicone rubber
Target Market(s) North America, Oceania, Southeast Asia, Eastern Europe, Africa(except Middle East), Latin America, Japan & Korea, Middle East & South Asia, Mainland China, Western & Southern Europe, Northern Europe, Central & Southern Asia, Middle East
