new design solar controller for off-grid solar system use

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Product Description

Product Details

Basic Specification

LED brightness	200lm/2w
Output voltage	12V
USB output	5V
Battery	lifepo4 battery

Detail Description

We are professional in customize LED lighting, recharegeble battery, and solar system products, pls refer more information at
Video show the off grid solar system: http://youtu.be/O-qCrwgCDvo

Features:

With aluminum case, circuit board encapsulation. Ideal for marine application

12V automatic recognition

High efficient Series PWM charging, increase the battery lifetime and improve the solar system performance.

Use MOSFET as electronic switch, without any mechanical switch

Widely used, automatically recognize day/night.

Intelligent timer function, enhance the flexibility of street light system.

Gel, Sealed and Flooded battery type option.

Adopt temperature compensation, correct the charging and discharging parameters automatically and improve the battery lifetime.

Electronic protection: Overheating, over charging, over discharging, and short circuit.

Reverse protection: any combination of solar module and battery.

Specification:

Controller voltage	12V
Controller current	8A
No load consumption	<10mA
Solar input voltage	18V
Low voltage disconnection	>11.4V
Low voltage reconnection	<12.5V
High voltage disconnection	14V-15V
Output ports	6ports for light, one for solar input, one for external battery
Protection against reverse polarity	Both design in the solar panel and battery side
Load side short circuit protection	Yes
Reverse leakage current	<500mA
USB output total current	2A
PCB	Glass epoxy,Metal core printed circuit board(MCPCB)
Temperature range	–5° C to 40° C.
Other protection	against direct entry of dust, moisture, oil, and smoke
Warranty	3.5years for the electrical parts
