Waterproof 3528 SMD LED Strips

LED type:3528 SMD LED
60 LED per meter
LED Chips: Epistar Taiwan
Life time: 50000 hours
Warranty time: two years
Environment-friendly
Saving energy much more
More color for choise
Certifications: CE, Rohs
 Main features

Description	LED strip
Light sourcing	3528 SMD	Size	LED quantity:30LED/M; 60 LED/M Available length: 0.5-5M; Width:8mm of FPC;
Beam Angle	140°	Chip quantity	1pc
Available Color	White	Red	Yellow	Blue	Green	Warm white
Luminous intensity/LED	1800mcd	400mcd	400mcd	300mcd	1200mcd	1800mcd
Wave length/nm	/	622- 627	588- 592	465- 470	515- 520	/
Input Voltage	12VDC or 24VDC	Working current/SMD	20mA
Available condition	indoor	Non-Water proof
Life time	50000 hours
Features	3 pcs SMD per unit. It could be cut between each unit freely. With flexible shap and can be installed on any uneven side 3Madhesive on back More colorful color for choice low current, low power for save energy 5Mper reel per anti-static bag


Applications:

1. Car decoration
2. Architectural decorative lighting
3. Archway,canopy and bridge edge lighting
4. Amusement park, theater, and aircraft cabin mood lighting
5. Emergency hallway lighting
6. Auditorium walkway lighting
7. Stairway accent lighting
8. Backlighting for signage letters
9. Backlighting for signage letters
10. Channel letter lighting
11. Emergency exit path lighting
12. Cove lighting

Attention:
1. Storage Temperature: -40 to +80℃
  Operation temperature: -25 to +60℃
2. Installation environment must be smooth, clean and dry.
3. The part of LED componets can not be fixed on the surface of charp edge.
4. The LED strips should not be collided or crushed with other objects.
5. Following the cutting line, the LED strips can be cut.
Packaging:
Now waterproof: 5M per reel; 80 reels per carton; the gross weight of carton: 6.8KGS; the size of the carton: 48X32X45CM;
Waterproof: 5 M per reel; 40 reel per carton; the gross weight of the carton: 14KGS; the size of the carton: 48X32X45CM
