3528 SMD T8 LED Tubes

T8 3528 SMD 1.5M 24W LED tubesBasic features:High luminance LED source: 7-7.5LM/3528SMDLong life time with over 50000 hoursSaving energy much moreNo flicker, no radialization,little CO2 produceEnvironment friendly, no Hydrargyrum and other harmful material in the tubeSpecial structure with aluminium cover and aluminium PCB for good heat eliminationSuper quality aluminium: heat elimination factor: 2.8Super quality PVC material: origin in JapanHigh efficiency factor of driver: >90% Environment requirements:Working teamperature: Working temperature: -20 degree to 40 degreeStorage temperature: -30 degree to 60 degreeWorking humidity: 30% to 85%Storage humidity: 10% to 90%Installation guide: 1.Take away the starter and ballast on your current fluorescent tube fixture2.Open the cover of the bracket and revice the method of wire connect as bellow3.Close the bracket cover and install the LED tube.

Description T8 LED tubes Lighting Source 3528 SMD LED; 7-7.5LM/ LED Available Length 1.5M(400LED) 1.2M(364LED) 1.2M(312LED) 1.2M(252LED) 0.9M(240LED) 0.6M(180LED) Luminous flux 2500LM 2200LM 1900LM 1764LM 1500LM 1100LM Power 24W 22W 20W 18W 15W 10W Material 1/2 AL + 1/2 Milky PC 1/2 AL + 1/2 clear PC Efficiency 90% Life time Over 50000 hours Available Color warm white pure white cold white Color temperature 2700K-4500K 4500K-5500K 5500K-6500K Certifications CE, ROHS, UL
