3528 T8 SMD LED Tube Light

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Product Description

Basic Specification

Tube length: 1200 mm / 4 Ft

Light sources: 252 pcs SMD 3528 LED

Beam angle: 170°

Emitting color: Warm White, Neutral White, Cool White

CCT: WW: 2700K ~ 3500K, NW: 3500K ~ 5000K, CW: 5000K ~ 7000K

CRI: WW: Ra≥80, NW: Ra ≥75, CW: Ra≥70

Luminous efficacy: 80 ~ 110 lm / W

Luminous flux: WW: 1250 lm / NW: 1550 lm / CW: 1700 lm ( ±10% )

Illuminance: WW: 300 lux / NW: 350 lux / CW: 400 lux ( ±10% @ 1m )

Input voltage: AC 120V / 240V, 50 ~ 60 HZ

Power dissipation: 18W ±10%

Housing material: Aluminium + PC

Cover effect: Transparent / Milk White

Base type: G13, Bi-pin

Box size: (1300x245x170mm)

Carton size: (1330x750x450mm) 20 pcs / Carton

NW: 8.212kg GW: 8.56kg

Operating conditions: -20℃ ~ +40℃, 30% ~ 85% RH

Storage conditions: -30℃ ~ +60℃, 10% ~ 90% RH

Payment Terms	L/C, T/T
Minimum Order	10PCS
Lead Time / Delivery Time	5 Day(s)
Sample Available	YES
Target Market(s)	North America, Oceania, Southeast Asia, Eastern Europe, Africa(except Middle East), Hong Kong/ Macao/ Taiwan, Latin America, Japan & Korea, Western & Southern Europe, Northern Europe, Central & Southern Asia, Middle East, Mainland China
