Automatic SMTechnology X1 soldering station
Your message must be between 20 to 2000 characters
Contact NowBasic Specification
| Brand Name | SMTechnology |
|---|---|
| Input Voltage | 110/220v |
| Output Temperature | 150-450℃ |
| Temperature Stability | ±1℃ |
| Output Power | 80W |
| Type | Electronic Assembly Line |
| Power Voltage | 220V |
Detail Description
SMTechnology X1 Temperature controlled soldering station
Specifications:
- Product name: X1 intelligent soldering station
- Model No. : X1
- Brand: SMTechnology
- Power consumption: 80W
- Temperature control range:150~450°C
- Temperature stable: ±1°C
- Output voltage: 24V
- Resistance between tips: Below 2Ω
- The potential between tips: Below 2mV
- Pacakge dimension: 35*27*17.5CM
- G.W: 3.2KGS
Features:
- The comparation between soldering master X1 and WELLER WSD81
Soldering Master X1: Condition:Set temperature: 350°C solder wire dia. :1.0mm
WELLER WSD81:the interval between soldering points: 3S solder length :15mm
Soldering Master X1:The temperature largest drop to 340°C,in two secs, the temperature will increase to 350°C
WELLER WSD81:The temperature largest drop to 330°C,in two secs, the temperature will increase to 340°C
- Adjusting the temperature automatically
You just need to put the soldering tips on the sensor of the temperature adjusting module for 30secs, the temperature will be very precise.
- Sensor dormancy
The soldering station will enter into dormancy if the soldering handle is put in the iron holder, and will start working once the soldering handle is moved from it.After working continually for eight hours, the temperature of soldering handle is still 40°C
Assembly item:
| No | Name | Qty | Equipment descriptions |
| 1 | host | 1 | standard |
| 2 | Iron hold | 1 | standard |
| 3 | Handle wire | 1 | standard |
| 4 | Temperature adjustment module | 1 | standard |
| 5 | solder iron | 1 | Q1 Series tips |
| 6 | Temperature adjustment connector | 1 | standard |
| 7 | Sleeping connect wire | 1 | standard |
Additional Information
| Payment Terms | T/T, Western Union |
|---|---|
| Minimum Order | 1 unit |
| Lead Time / Delivery Time | 5 Day(s) |
| Sample Available | NO |
| Delivery Details | Within 3 days after getting the payment |
| FOB Port | Shenzhen |
| Loading Info | FOB/ Express/air |
| Packing Info | Carton packing4 unit / carton |
| Target Market(s) | Africa(except Middle East), Eastern Europe, Hong Kong/ Macao/ Taiwan, Japan & Korea, Latin America, Mainland China, Middle East, North America, Northern Europe, Oceania, Central & Southern Asia, Southeast Asia, Western & Southern Europe |
