Die-casting wide Beam Angle LED Candle Bulb Light High Quality Ener

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Product Description

Product Details

Basic Specification

Lamp Base	B22/E27
Power	3W
Life	30000Hs
Lamp Base	E26, E27
Color Tones	Natural White
Illuminant	SMD
Light Source Chip	Epistar
Voltage	90-260V
Lamp Holder	E26, E27
Dimmable	No
Shape	Candle Shape
Package	Yes
Power Storage or Not	No
Material	Aluminum, PC

Detail Description

1.This product meets the standard of CE certification.
2.With internal Constant Current Power Supply.
3.Use the most mature international well-known LED SMD5630 as the light source, which can ensure the led Bulb brightness and long lifetime, also can reduce the light decay.
4.Use the high quality aluminum PCB for LED’s better heat dissipation.
5.High-grade Transparent PC cover with nice light transmittance (>95%).
6.300º beam angle makes the lighting effect better.
7.Ambient temperature:-20℃~40℃, surface temperature: 42℃~45℃.
8.No mercury, lead or other hazardous materials; no radiation, no electromagnetic radiation, no frequency flash, instant startup, no hurting eyes.

Electrical Characteristics	Optical Properties
Power Supply	With Internal Constant Current Power Supply	LED Type	SMD5630
Input Voltage	AC85-265V / 50-60Hz	LED Q’ty	10pcs
Rated Power	5W	Lumen	350-400 lm
Actual Power	5W±0.5W	CRI	≧70 Ra
Power Factor	0.95-0.98	Beam Angle	300°
Life Time	≧30000H	CCT	2800-3200K/4000-4750K/ 5500-6500K
Standard Dimensions
Product Dimension	N.W.	Packing Dimension	G.W.
102mm(L)* Ø60mm	0.063kg	6565110mm	0.088kg

Dimension: (mm)
Packing Info:

Application:

Widely used in factory, supermarket, park, entertainment plaza and less traffic or path road lighting

Benefits of led bulb:

1. Solid-state, high shock / vibration resistant
2. No RF interference, No buzzing noise
3. No fluorescent flickering
4. No hazard of mercury or lead entering the environment
5. Maintenance free, easy installation
6. Long lifetime 30, 000+ hrs (5+ years)
7. Low power consumption, high intensity

Applications of led bulb:
1. Bus, shuttle, railcar passenger interiors
2. Uninterrupted emergency lighting
3. Focused reading and Task lighting
4. Interior design
5. Closet illumination
6. Cove lighting
7. Marine recreation applications
8. Concealed accent lighting
9. Edge lighting
10. Under counter lighting
Warranty
FreeApplication warranty for 3 years except natural disasters and man-made factors.
Application

Lighting Knowledge
Comparison Table for LED lights, compact fluorescent lamp, incandescent lamp and other light sources

	LED light	CFL/FL	Incandescent lamp	High pressure sodium lamp
Luminous efficacy	80lm/w	60lm/w	20lm/w	100lm/w
Power supply efficiency	95%	65%	/	50%
lighting efficiency	85%	60%	60%	55%
light fixture efficiency	90%	60%	60%	51%
service time	50,000 Hr	1,800Hr	1,800Hr	6,000Hr

Then the actual efficiency of each lighting fixture is calculated out as below:

LED light: 80lm/w*95%*85%*90%=58.14lm/w

CFL/FL: 60lm/w*65%*60%*60%=14.04lm/w

Incandescent lamp: 20lm/w* 60%* 60%=7.2 lm/w

High Pressure Sodium Lamp:100lm/w* 50%* 55%* 51%=14 lm/w

It can be seen that, the actual efficiency of LED light is 4 times that of CFL/FL, 8 times that of incandescent lamp,4 times that of high pressure sodium lamp.

Factory View:

Additional Information

Payment Terms	L/C, T/T, Others
Minimum Order	100PCS
Lead Time / Delivery Time	30 Day(s)
Sample Available	YES
Delivery Details	3-7 days for sample order,10-12 days for regular order
FOB Port	Shenzhen
Loading Info	customized
Packing Info	neutral packing
Target Market(s)	Africa(except Middle East), Eastern Europe, Hong Kong/ Macao/ Taiwan, Latin America, Mainland China, Middle East, North America, Northern Europe, Central & Southern Asia, Southeast Asia, Western & Southern Europe
