LED Strip Light (5050SMD Silicon Waterproof)

SMD3528 Flexible LED Strip Lights for Cabinet

Description
This non-waterproofflexible LED StripLighting 60pcs/m is a flexible, slim, high brightness, single color strip ideal for all interior applications.  This LED Stripsoffers a great solution for everything from home projects to serious architectural lighting.


Features:
1. Continuous length Flexible LED light strips
2. Runs on 12-voltage systems like solar cell charged batteries
3. 120-degree wide angle illumination
4. Almost no need Maintenance, with 3M adhesive tape on the back for easy installation
5. Long life: white LED: 50, 000+ hours
6.Better performance and more reliable quality

Specification:
Model No.: SZ-SMD3528RGB-60-A
1. Type: SMD3528 Flexible led strip
2. Dimension: 5000mm (L) x 8mm (W) x 2.5mm (Thickness) (5 meters/reel, 3-LEDs Cuttable)
3. LED Quantity: 300PCS SMD3528 LED per reel
4. Color Range: RGB
5. Wavelength: R: 620-630nm, G: 510-525nm, B: 455-470nm, Y: 585-595nm
6. Energy Consumption: 24W per reel
7. Working Voltage: DC 12V
8. Current Consumption: 2A per reel
9. Beam Angle: 120 Degree
10. International Protection: IP20 (non-waterproof), IP65 (Crystal Epoxy Waterproof), IP66 (Solid Cover Tube Waterproof) IP67 (PVC+ Crystal Epoxy Waterproof)

Related products:

Model	LED Type	LED Quantity	LED/lumen	Color	Warranty
SZ-FS3528RGB-60-A	SMD3528	60pcs/m	High brightness	RGB	2 years
SZ-FS3528RGB-120-A	SMD3528	120pcs/m	High brightness	RGB	2 years
SZ-FS3528RGB-60-B	SMD3528	60pcs/m	High brightness	RGB	1 years
SZ-FS3528RGB-120-B	SMD3528	120pcs/m	High brightness	RGB	1 years



One-stop accessories
Top quality suppliers of raw material
We owned a full set of superior materials for customers choosing, 100% respect customers needs.
Services advantages

RGB Controller
Power Supply: DC12V-24V
Output Type: Three
Max Load Current:2A/channel
Max Load Power:72W,144W
Remote Type: IR control
Max keys: 24 keys

Power Driver
Shell Type: Aluminium housing
Power Supply: DC12V
Input Type: RGB 3 channels
Output Type: RGB 3 channels
Max Load Current:4A/channel
Max Load Power:144W

Enclosure
Universal AC input/Full range
Overload protechtions
100% full loaded aging
Working temperature reach 60°C
Suffer 5g vibration testing
High efficiency and high reliability


Application
This 60PCS 3528 Flexible LED Stripis widely used to architectural decorative lighting, archway, canopy & bridge edge lighting, amusement park, theater & aircraft cabin mood lighting, emergency hallway lighting, auditorium walkway lighting, stairway accent lighting, concealed lighting, backlighting for signage letters, channel letter lighting, emergency exit path lighting and cove lighting.
