2012 NEW Hot Energy Saving Lighting 5W LED Ceiling Downlight

Energy Saving LED Ceiling Downlight


Description
SZODM, professional OEM/ODM manufacturer made theLED Downlighting5W, It’s a recessed architectural high power led downlightthat utilizes 5pcs super bright LED to deliver 480 lumens of high quality light, with an amazing efficacy low light decay.


Features:
1. Save Energy: 5W led downlight could replace 25W traditional downlight.
2. Eco-friendly: long life, energy saving and no mercury
3. Seamlessly integrate some truly unobtrusive recessed lighting into your design project.


Specification:
Model: SZ-D05W-A
1. LED: 5x1W High Power LED
2. Luminous Flux: 480lm
3. Energy consumption: 5watts
4. Color Temperature (K): 7000K-8000K (Cool White) / 3000K-4000K (Warm White),
4000K-5000K (Nature white)/5000K-7000K (Pure white)
5. Color: Warm White/Cool White, Red, Green, Blue and Yellow available
6. Color Rendering Index (CRI): 73 (Cool White), 72(Warm White)
7. Beam Angle: 120 degrees  --- Lens: 20/30 degrees
8: Lens Type: Clear
9. Operating Temperature: -10 ~ 65 degrees Celsius
10. Input Voltage: AC100-240V
11. Housing Materials: Aluminum Alloy(OSP)
12. Dimension: H60*D110mm
Punched size: 93mm


Related products:

Model	SZ-D05W-A	SZ-D05W-B
Light Power	5W	5W
Dimension	H60*D110mm	H60*D110mm
Punched size	≧93mm	≧93mm
Single LED Lumen	100-110LM	80-90LM
LED Quantity	5pcs	5pcs
Warranty	2years	1years



One-stop accessories
Top quality suppliers of raw material
We owned a full set of superior materials for customers choosing, 100% respect customers needs.
Services advantages

LED
Type of LED: High Power LED
Power: 1W/LED
LED Lumen:100-110lm
Lifespan: 50,000H
Color temperature: 3000K-8000K

Power Driver
Input Voltage: AC85-265V, 50/60Hz
Over Voltage Protection
EMC Standards
Working Temperature:-10~65°C
High efficiency, long lifespan and high reliability

Enclosure
Materials: Aluminium alloy +Lens
Good thermal performance
Energy conservation
Good beam Angle for space lighting
Different Sets for choice
Application
This down lighting 5W is widely applied to airports, hotels, homes, offices, schools, hospitals, display case lighting, under cabinet lighting, art lighting, boat lighting, fashion store, and accent lighting.
