48V10Ah Ebike Polymer Battery Pack used for Electric Bicycle
Your message must be between 20 to 2000 characters
Contact NowBasic Specification
Detail Description
-
48V Polymer battery pack, Electric bicycle battery 48V 10Ah with Al case, Charger
1. Model: KY-4810-A with 48V 10Ah
2. Specification:
48V 10Ah, 20A discharge current.
Dimension: 389x76x110mm(HxWxL)
Weight: 6.5kg
including to Charger, PCB, BMS.
No
Item
General Parameter
Remark
1
Rated Capacity
10Ah
Standard discharge(2A) after standard charge
2
Minimal Rated
Capacity
10Ah
Standard discharge(2A) after standard charge
3
Nominal Voltage
48V
Mean Operation Voltage
4
Cycle Life
Higher than 70% of the Initial Capacities of the Cells
Carry out 500cycle
Standard discharge(2A) after standard charge
Discharge: 2Ah to 39V
Rest Time between charge/discharge : 30min.
Temperature:20+/-5Degrees Celsius
5
Voltage at end of
Discharge
39V
Discharge Cut-off Voltage
6
Charging Voltage
54.6V
7
Standard charge
2A CC(constant current)charge to 54.6V, then CV(constant voltage 54.6V)charge till charge current decline to ≤0.01C
Charge time : Approx 6h
8
Standard discharge
Constant current 2A
end voltage 39V
9
Maximum Continuous Charge Current
1C(15A)
10
Maximum Continuous Discharge Current
2C(20A)
11
Operation Temperature Range
Charge: 0~45Degrees Celsius
60+/-25%R.H.
Bare Cell
Discharge: -10~60Degrees Celsius
12
Storage Temperature Range
Less than 1 year : -20~25Degrees Celsius
60+/-25%R.H.
at the shipment state
Less than 3 months: -20~40Degrees Celsius
13
Weight
Approx: 6.5Kg
14
Pack Dimension
High:389mm
Width: 76mm
Long: 110mm
3. Performance And Test Conditions
3.1 Standard Test Conditions
Test should be conducted with new batteries within one week after shipment from our factory and the cells shall not be cycled more than five times before the test. Unless otherwise specified, test and measurement shall be done under temperature of 20+/-5Degrees Celsius and relative humidity of 45~85%. If it is judged that the test results are not affected by such conditions, the tests may be conducted at temperature 15~30Degrees Celsius and humidity 25~85%RH.
3.2 Measuring Instrument or Apparatus
3.2.1 Dimension Measuring Instrument
The dimension measurement shall be implemented by instruments with equal or more precision scale of 0.01mm.
3.2.2 Voltmeter
Standard class specified in the national standard or more sensitive class having inner impedance more than 10kΩ/V
3.2.3 Ammeter
Standard class specified in the national standard or more sensitive class. Total external resistance including ammeter and wire is less than 0.01Ω.
3.2.4 Impedance Meter
Impedance shall be measured by a sinusoidal alternating current method (1kHz LCR meter).
3.3 Standard Charge\\Discharge
3.3.1 Standard Charge: 2A
Charging shall consist of charging at a 2A constant current rate until the cell reaches 29.4V. The cell shall then be charged at constant voltage of 42 volts while tapering the charge current. Charging shall be terminated when the charging current has tapered to 0.01 C5A. Charge time: Approx 4.5h, The cell shall demonstrate no permanent degradation when charged between 0 and 45 Degrees Celsius.
3.3.2 Standard Discharge: 2A
Cells shall be discharged at a constant current of 2A to 21Volts @ 20º ± 5C
3.3.3 If no otherwise specified, the rest time between Chare and Discharge amount to 30min.
4. Environmental and Safety
The cell is approved according UL 1642. This battery meets the requirements of Battery Directives and the battery parts are RoHS-Compliant.
Additional Information
| Payment Terms | T/T, L/C, Others |
|---|---|
| Minimum Order | 10units |
| Lead Time / Delivery Time | 15 Day(s) |
| Sample Available | YES |
| Delivery Details | TT in advance, FOB HK or Shenzhen |
| FOB Port | Hong Kong |
| Loading Info | By Courier, UPS and so on |
| Packing Info | Package: Export Standard PackingDimension of carton:480*300*190mmWeight:8kg/ctn |
| Target Market(s) | Eastern Europe, Hong Kong/ Macao/ Taiwan, Japan & Korea, Latin America, Mainland China, Middle East, North America, Oceania, Western & Southern Europe |
