outdoor use infrared thermal imaging camera

outdoor use infrared thermal imaging camera

Features:

SProvide special software in the iPhone or android mobile phone
Compression format :Motion-JPEG
Signal system :CMOS 300,000 pixel
Rotation angle:Horizontal:355° vertical: 90°
Nightvision :66Φ3 LED lights

Detailed Specifications


Model:F-M1BF
Features	Superiority	Support monitor via computer and most of intelligent cellophane on the market(such as Android ,Iphone cellphone
mobile software	Provide special software in the iPhone or android mobile phone
DDNS（free）	Built in free DDNS system,like http://demo.easyn.hk, \'demo\' is serial code
CMS software	EasyN multi-window mangement software
System security	Supports three-level account, password, user multi-level authority management
CPU	Operation system	Embedded Linux OS
Microcomputer processor	32Bit RSIC Embedded Processor
Network	Network interface	RJ-45   10/100Mb   self-adaptable Ethernet slot
Protocol	Support TCP/IP、HTTP、ICMP、DHCP、FTP、SMTP、PPPoE etc.
Wireless	WIFI,802.11 b/g
IP mode	Dynamic IP address, static IP address, PPPOE
Online visitor	Streaming in (640 * 480)directly connected , Support 4 visitors at the same time
Streaming in(320*240)directly connected , Support 4 visitors at the same time
Streaming in (160* 120)directly connected , Support 4 visitors at the same time
Video	Compression format	Motion-JPEG
Signal system	CMOS  300,000  pixel
Frame rate	25fps
Zoom	Three times optics zoom
Resolution	VGA(640*480),QVGA(320*240) ,QQVGA(160*120)
Image adjustment	Brightness, contrast.
WB, BLC	Auto
LUX	0.3LUX/F1.2
SNR	>48dB
Lens	Zoom lens 5-15mm
Audio	Compression format	G.711/G.726
Input	Built-in  Mircophone
Output	Video output
PTZ	Motor	Built-in motor control
Rotation angle	Horizontal:355°         vertical: 90°
Preset	Support 15 presets
Nightvision	Nightvision	66Φ3 LED lights      IR distance: 20m
Alarm	Input/output	Motion detection/FTP server , email notification, HTTP
Alarm detection	Motion detection;Detection sensitivity Settings
Detection area	One
Alarm notification	IO linkage;FTP server , email notification, HTTP
Others	Shape material	aluminum alloy
environment	Water-proof  outdoor use
Power supply	12V 1A
Operating temperature	-10~50°C
Operating humidity	10%~90%RH
Dimension	Item size：200 x 160 x 180mm     (L*W*H)
Package size：255 x 195 x 240mm     (L*W*H)
Weight	Item weight：1000g （Note:for real products ）
Package weight：1370g
Accessories	Power adapter,CD,manual,warranty card,srews ,bracket ,antenna
System	System requirement	Microsoft Win98 SE/ME/2000/XP,Vista，Win7,Internet Explorer8.0,
Certification	Certificate	CE FCC ROHS ISO

WEB UI Interface



MobileAPP



Quick Installation Guide






Certificates



Our factory




Frequently Asked Questions

Q: Why can’t I find the IP camera using the finder (searching tool)?
A: 1. Please check whether the IP camera and searching tool are located in the same LAN network;
2. Please check the connection of the internet cable and power.[Under normal circumstances, power   light (yellow) is constantly on, network light (green) constantly flickers]
3. The Firewall installed in the computer may have blocked the IP camera.

Q: Where can we download the cell phone visiting program?
A: Please visit http://f.easyn.com or scan the QR code on the product to download the corrected APP.

Q: How can I set my IP camera in the same network segment as my PC in LAN?
A: First you can use searching tool to find out the camera, then click the auto set button.

Q: Why is the image from the IP camera’s image too white or dark?
A: Please try to modify the camera mode at the IP caera interface.

Warranty Terms

EasyN provides 12 months warranty service on your product. Your warranty card is an important document. You will need to present this warranty card to benefit from our warranty service.

Terms & conditions:
a) Free-of -Charge maintenance period of the product is 12 months. During this time, we can repair it for free (Damages not caused by misuse or vandalism). For reparation after guarantee period, a maintenance fee will be charged.
b) During the warranty period, for breakdown caused by misuse or other reasons that are out of the range of warranty, users can repair the products by showing this card. We will only charge for components.
c) When the products need maintenance, please hand in the warranty card together with the products to the manufacture or local distributor.
d) Opening the inside of the products and tearing up the sealing label privately is out of the warranty range.
e) We do not repair the damaged item after it has been modified or added other functions.

Under the following circumstances, the maintenance will be charged:
1. Period check, maintenance or change components due to normal attrition.
2. Damages due to crash, extrusion, artificial flooding, moisture or other personal reasons.
3. Damages due to floods, fire, lightning strike and other natural calamities or force majored incidents factors
4. Repaired item by non-authorized repair centers.
