5V charge for mobile phone pass CB ,CCC.GS ,CE BS,ETL ,SAA,KC,PSE
Your message must be between 20 to 2000 characters
Contact NowBasic Specification
| Dimension(mm) | 66*24*31.5 |
|---|---|
| color | black /White |
| N.W/PCS | 65g |
| out put | 5V 1A |
| G.W/cartor | 11KG |
| Rated Current | Other |
| Real Load | 5 |
| Output Type | Multiple |
| Hole Digits | 2 |
| Zone Of Application | Other |
Detail Description
5V charge for mobile phone pass CB ,CCC.GS ,CE BS,ETL ,SAA,KC,PSE
Key Specifications:
5v charge for mobile phone From Manufacturer &Factory&Exporter
High quality, factory supply Certificated Power supply 5V 1A with US, EU,AUS, UK plug. 5V charger with CE,KC for mobile phone MP3, Tablet
With various Plug types
High quality
| MODEL NO. | OUTPUT(V) | OUTPUT(A) | TPUT(W) MAX |
| AK00G-XXXYYYWZ | 3-4.9 | 0.01-1.20 | 5W |
| AK00G-XXXYYYWZ | 5-7.5 | 0.01-1.00 | 5W |
| AK00G-XXXYYYWZ | 7.6-10.0 | 0.01-0.66 | 5W |
| AK00G-XXXYYYWZ | 10.1-12.5 | 0.01-0.49 | 5W |
| AK00G-XXXYYYWZ | 12.6-15 | 0.01-0.39 | 5W |
Reliability:
Burn in: 100% full load, 40±5℃, 4 hours
Leakage Current: 0.25mA Max. at 240Vac
Voltage Withstand (Between Primary and Secondary): 3000Vac,60S, 5mA Max.
Insulation Resistance (Between Primary and Secondary): 20MΩ min at 500V DC
MTBF: over 30,000 hours @ 25 ℃ with full load according to MIL-HDBK-217F.
Protection:
Short Circuit Protection: The power supply will recover automatically after fault removed
Over Current Protection: The power supply will recover automatically after fault current removed
Over Voltage Protection: The power supply will be shutdown when output voltage exceeds rated voltage by 150%-180%, and recover automatically after fault removed.
Environmental Specifications:
Operating Temperature: 0º C to 40 º C at maximum load
Storage Temperature: -20 º C to 85 º C
Storage Relative Humidity: 5% to 95% non-condensing
Immunity:
Radiation: 61000-3-2
Electrostatic Discharge: 61000-4-2
Electromagnetic Field Radiation：61000-4-3
Instantaneous Discharging：61000-4-4
Surge：61000-4-5
Conducted Interference：61000-4-6
Voltage Interruption and Variation：61000-4-11
Charge EMC Complianc
North American Market FCC: FCC Part 15 Class B
European Market EMC: EN55013/55022 Class B
Chinese Market: GB9254-2008/GB17625.1-2003/GB13837-2003/GB17625.1-2003
Australian Market C-TICK: CISPR13/22 Class B
5W Wall Plug-in Adapter Package
| N.W/pcs | Pcs/Carton | G.W/Carton | Dimension (mm) | White Box (mm) | |
| CCC UL PSE Certified Adapter | 65g | 135 | 11.0kg | 66*24*31.5 | L85*W28*H80 |
| GS KC Certified Adapter | 71g | 135 | 11.8kg | 66*24*54.5 | L85*W28*H80 |
| BS Certified Adapter | 71g | 120 | 10.8kg | 60*49.5*44 | L90*W50*H70 |
| SAA Certified Adapter | 78g | 120 | 11.6kg | 66*39*46 |
L90*W50*H70 |
More picture
Framework Specifications
Charge Certificates Obtained:
CB Report (Global): IEC60950-1/IEC60065/IEC61558-2-7
CCC Certificate (China): GB4943-2001/GB8898
GS Certificate(Europe): EN60950-1/EN60065/EN61558-2-7
CE Certificate(Europe): EN55022, 55024/55013,55020/55014-1,2
BS Certificate(Britain): BS EN60950-1/BS EN60065
ETL Certificate(North America): UL60950-1/UL60065
SAA Certificate(Australia): AS/NZS 60950.1 AS/NZS 60065
KC Certificate(Korea): K60950-1/K60065
PSE Certificate(Japan): J60950-1/J60065
CE Certificates
CB Report
ETL Certificate
GS Certificate
BS Certificate
SAA Certificate
CCC Certificate
KC Certificate
PSE Certificate
ISO 9001:2008
ISO 14001:2004
Additional Information
| Payment Terms | T/T |
|---|---|
| Minimum Order | 1000 |
| Lead Time / Delivery Time | 20 Day(s) |
| Sample Available | YES |
| Delivery Details | 20 working days after receiving the advance payment to All-Key account |
| FOB Port | Shenzhen |
| Loading Info | Ocean/Air shipping or DHL,UPS,FedEX, TNT etc. |
| Packing Info | Packing material based on Carton (designed by All-Key): Pe bag+white box+carton |
| Target Market(s) | North America, Oceania, Southeast Asia, Eastern Europe, Africa(except Middle East), Hong Kong/ Macao/ Taiwan, Latin America, Japan & Korea, Mainland China, Western & Southern Europe, Northern Europe, Central & Southern Asia, Middle East |
