IP65 Aluminium led sensor lamp for emergency lighting

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Product Description

Basic Specification

material	die-cast aluminum base and PC prismatic diffuser
input voltage	100-240V AC
IP rating	IP65
emergency function	3 hours
sensing function	microwave motion sensor
IP	IP65
Voltage	110-220V
Light Source	LED

IP65 Aluminium led sensor lamp for emergency lighting

Product features

1 LED lighting source, green and energy saving;

2 IP65, available for outdoor use;

3 Die-cast aluminum body and Polycarbonate(PC) diffuser;

4 3 Hours emergency(option available);

5 Microwave/Motion sensor:

--Automatic dims when detected area is unattended

--Adjustable range (1-8m)

6 Anti-glare design: against from the dizzy light;

7 No UV, no infrared, no other Hazardous Substances;

8 No noise, no flicker, resistance from vibration;

9 CE&ROHS compliant and two years warranty;

Technical parameters

Input voltage ( 50/60Hz)	AC 100-240V
Power consumption	20 W (24.5W for emergency versions)
Power factor(PF)	>0.9
LED Driver output voltage	DC 30V
LED Driver output current	550mA ±25mA
Light source	3528SMD LED
Color Temperature	3000K /4000K /6000K (optional)
CRI	Ra>80
Flux luminous	1600~1800Lm
Luminous efficacy	87Lm /W for SN-ES2001-C-2 67.5Lm /W for SN-ES2001-E-2 80Lm /W for SN-ES2001-S-2 65Lm /W for SN-ES2001-2
View angle	110°
Housing material	Die-cast aluminum base , PC prismatic diffuser
IP Rating	IP 65
Life Span	Up to 35,000 hours
Operation temperature	-10 deg C to 40 deg C
Dimension	31531599mm
Package	330330110mm
Net Weight	3.05KG(approx)
Emergency:
Type	Maintained
Battery(High-Temperature)	9.6V 3.2AH Ni-MH rechargeable
Emergency output	30% nominal power
Emergency duration	>3 Hours
Charge time	< 12Hours
LED indication	Red: charging; Green: fully charged; Yellow: battery fault or disconnected
Test button	AC power on: Push and hold the button to enter emergency mode; release button to come back AC power mode
Microwave Sensor:
Sensor range	180 degree; 0.5 - 8M (adjustable)
Sensing interval	10s to 5min max (adjustable)
Sensing interval output	25% normal power

Mechanical structure

High quality pictures

Payment Terms	T/T, Western Union
Minimum Order	1
Lead Time / Delivery Time	15 Day(s)
Sample Available	YES
Delivery Details	sample order 2-7 working days; bulk order 15-30 working days
FOB Port	Shenzhen,
Loading Info	by express, by air, by sea
Packing Info	standard export package
Target Market(s)	North America, Oceania, Hong Kong/ Macao/ Taiwan, Western & Southern Europe, Northern Europe
