High bright motion sensor outdoor lamp, 12W LED, IP65
  • High bright motion sensor outdoor lamp, 12W LED, IP65
  • High bright motion sensor outdoor lamp, 12W LED, IP65
  • High bright motion sensor outdoor lamp, 12W LED, IP65
High bright motion sensor outdoor lamp, 12W LED, IP65
High bright motion sensor outdoor lamp, 12W LED, IP65
High bright motion sensor outdoor lamp, 12W LED, IP65

High bright motion sensor outdoor lamp, 12W LED, IP65

Quantity:

Your message must be between 20 to 2000 characters

Contact Now
Basic Info
Basic Info
Product Description
Product Description
  • Product Details

Basic Specification

light source SMD LED
IP grade IP65
sensor microwave sensor
sensing output 25% of nomial power
power 8W-12W
Application Architectural Lighting, Bridge, Car Park
Voltage 110-220V
Material Aluminum, PC
IP IP65

Detail Description

High bright motion sensor outdoor lamp, 12W LED, IP65


Application :

-Public areas of hotel /restaurant
-Public areas of hospital
-Aisle /stair half /elevate hoistway of all kind of building
-Public areas of  Local Authority building
-Circulation area in high rise council housing
-Public areas of mall/supper-market
-Parks
-Pedestrian subways in city centres
-Permanent lighting for exterior market stalls
-Security lighting applications


Product Features:

  •   LED lighting source: green and energy saving;
  •   IP65: available for outdoor use;
  •   Anti-aging cover: Polycarbonate (PC) cover;
  •   Adequate emergency time: 3 Hours emergency(option available);
  •   Anti-glare design: no dizzy light;
  •   Healthy and safe: no UV, no infrared, no other Hazardous Substances;
  •   Stability: no noise, no flicker, resistance from vibration;
  •   Reliable: 2 years warranty.



Electric parameters:

Input   voltage ( 50/60Hz) AC 100-240V
Power consumption 12W
PF >0.9
LED Driver  output voltage DC 30V
LED Driver  output current 250mA  ±15mA
Light source  SMD LED
Color Temperature(CCT) 3000K /4000K/ 6000K (optional)
CRI  >75
Flux luminous 800-900Lm
Luminous efficacy 75Lm /W
View angle 110°
Housing material Die-cast aluminum base, PC prismatic diffuser
IP Rating IP 65
Life Span Up to 35,000 hours
Operation temperature -10 to 40
Dimension 390*110*90mm
Package 420*120*115mm
Net Weight 2.2KG(approx)
Emergency Function:
Type Maintained
Battery(High-Temperature) 9.6V 1.6AH Ni-MH rechargeable
Emergency output  30% nominal power
Emergency duration >3  Hours
Charge time < 12Hours
LED indication Red: charging;     Green: fully charged;
Yellow: battery fault or disconnected
Test button


AC power on:  Push and hold the button to enter emergency mode;  release button to come back AC power mode






Product Advantages:
  • High efficiency and energy saving: hi-lite, wide viewing angle and wide range of working voltage. It can take place of the traditional energysaving lamps and save more than 85% energy.
  • Environment protection: no infrared and ultraviolet ray, no heating effect,no lead and mercury, in a word, without any pollution to the environment.
  • Stability and durability: with more than 35000 hours lifetime, it is not affected by radiation; the material are durable,which makes the maintenance easier and more convenient.
  •  Packing specification: each piece is packed independently and environmentally.
  •  Certification:  passed CE, ROHS certification.
  •  Quality goal :Percentage of good products is more than 98%, final and timely shipments are more than 95%, custom complaint is less than one.


About emergency lighting function:

It is designed as EN1838 international standard.
Ni-MH rechargeable battery is applied.
In emergency mode, it can automatically switch to battery output, and the emergency duration for the light is more than 3 hours (customizable).
The built-in battery can be rechargeable up to 300 times.




Dimension (mm):



Product Details:






Application Effect:

Additional Information

Payment Terms T/T, Western Union, Others
Minimum Order 1 pcs
Lead Time / Delivery Time 5 Day(s)
Sample Available NO
Delivery Details sample order: 2-3 working daysbulk order: 2-5weeks
FOB Port Shenzhen
Loading Info By air or by sea
Packing Info Independent box with waterproof plastic bag12 pcs/cartonStandard exporting packing
Target Market(s) Oceania, Southeast Asia, Eastern Europe, Latin America, Western & Southern Europe, Northern Europe, Middle East
