wireless power charger power supply12V1A UA plug

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Product Description

Basic Specification

1,The specification of wireless power charger power supply:

12v power plug adapter
Input&Output	Voltage/Frequency Range	100～240VAC 50/60Hz
Input Current	≤0.3A
Rated Output	12V;1A;12W
Line/Load Regulation	±2% / ±5%
Ripple&Noise(Max)	≤200mV
Reliablility	Withstand voltage	I/P-O/P:3KVAC,60s, 5mA
Leakage current	0.25mA / 240VAC
Isolation resistance	I/P-O/P:100M Ohms / 500VDC / 25 / 70% RH
MTBF	30000hrs full load,based on MIL-HDBK-217F(25℃)
Temperature rise	80~100% load, 4hours
Protection	Over Load	>105% rated output power
Over Current	110%-150% rated output current
Short Circuit	Recover automatically after fault condition is removed
Safety	Safety Standard	UL60950-1, CSA22.2,IEC/EN60950 IEC/EN60065
EMI	Compliance to FCC part15 class B, EN55022, EN61204-3 class B
EMS Immunity	Compliance to EN61000-4-2,3,4,5,6,8,11, ENV50204
Harmonic Current	Compliance to EN61000-3-2,3
Environment protection & efficiency	RoHS	Compliance to CPSIA（H.R.4040）
No Load power consumption	<0.3W
Efficiency	IV or V
Package	Dimensions	76×42.5×67.5mm (LWH)
Packing	PE bag or white box
Environment	Working Temp	0 ~ +50 (℃)
Working Humidity	20% ~ 90% RH non-condensing
Storage Temp	-20~85(℃),10 ~ 95% RH

2,The advantage of wireless power charger power supply:

We are one of the manufacturer for all kinds of charger and adapter.
We can offer factory price,it’s very competitive.
We much highly value the quality of products,it’s more reliability,safety and environmental.
OEM&ODM is welcome.
MOQ is 1,000 and that we can offer the sample order.
Payment:T/T,West union and Paypal is accepted.

3,The picture of wireless power charger power supply:

Contact	Email	Skype	Mobile	Phone
Neil Liu		flinsales030	+85-18098920546	+86-755-29233890

4,The picture of our factory Shenzhen Jiakeyuan Industry Co.,Ltd:

Payment Terms	T/T
Minimum Order	1000
Lead Time / Delivery Time	20 Day(s)
Sample Available	YES
Delivery Details	Within 20 days after receiving your payment and confirming all the details
FOB Port	Shenzhen
Loading Info	FOB SHENZHEN
Packing Info	PE bag or white box,and export carton
Target Market(s)	North America, Oceania, Southeast Asia, Eastern Europe, Africa(except Middle East), Hong Kong/ Macao/ Taiwan, Latin America, Japan & Korea, Mainland China, Western & Southern Europe, Northern Europe, Central & Southern Asia, Middle East
